Front-Transition Card; Figure 6-12 Connectors On The Host Cpu Card - Sun Microsystems Netra CT Service Manual

Ethernet A port
FIGURE 6-12
6.2

Front-Transition Card

Note – The host CPU front-transition cards are only hot-swappable as long as the
host CPU card has been removed first.
If you encounter problems with the host CPU and/or the host CPU front transition
card, you may not be able to determine which card of the two is causing the
problems. Because of that, you might want to replace both cards when one of them
fails.
If you are removing and replacing a faulty card in the server, first to go
I
Section 6.2.1, "Removing a Host CPU Front Transition Card" on page
go to
If you are installing a new card in the server, go to
I
CPU Front Transition Card" on page
6-28 Netra CT Server Service Manual • January 2004
