FIGURE 6-15
7. After you have replaced the host CPU front transition card, get the replacement
host CPU card from the ship kit.
8. Go to the front of the server and install the host CPU card.
Refer to
6.3

Rear-Transition Cards

Note – The rear-transition cards are only hot-swappable as long as the
accompanying main card has been removed first.
This section gives procedures for the installation, removal, and replacement of the
following hot-swappable cards for rear-access models of the Netra CT 410 server and
Netra CT 810 server:
Section 6.3.1, "Host CPU Rear Transition Card" on page 6-32
I
Section 6.3.2, "Satellite CPU or I/O Rear Transition Card" on page 6-38
I
Section 6.3.3, "Alarm Rear Transition Card" on page 6-43
I
SCSI
Parallel
Ethernet B
TTY B
Connectors on the Host CPU Front Transition Card (Netra CT 410 Server)
Section 6.1.2.2, "Inserting a Main Card" on page 6-17
Chapter 6 Removing and Replacing Hot-Swappable Cards
C O
M
H O
T
S W
A P
H O
T S W
A P
for those instructions.
6-31
