Chapter 2: Setting Up an Origin200 System
46
5. Attach one of the power connectors at the rear of the carrier to the drive. Use
whichever connector fits conveniently for the position of the drive's power
receptacle. See Figure 2-13.
Carrier power
receptacle
Peripheral
power connector
Figure 2-13
Attaching a Power Connector to a 5.25-inch Drive
