Removing the System Cover, Tower Origin200 System
Figure 5-5
3. Open the chassis access door, as shown in Figure 5-6.
Using a #2 Phillips screwdriver, remove the four screws that secure the door to
the chassis (two at the rear of the door and two near the door hinge).
Swing the door out, away from the chassis.
Optional: You can remove the door by lifting it up slightly and away from the
chassis. In some cases, it may be easier to service the Origin200 if you remove
the chassis access door.
Removing the System Cover and Chassis Access Door
119
