Chapter 8: Installing and Configuring Peripherals
166

Removing 5.25-Inch Peripherals

Follow these steps to remove a 5.25-inch peripheral:
1. Remove the front door. See "Removing the Front Door" on page 116.
2. Remove the peripheral carrier, as shown in Figure 8-6.
Pull out the peripheral carrier handle. The handle flexes downward, allowing
access to two captive screws.
Using a #2 Phillips screwdriver, undo the two captive screws that secure the
peripheral carrier to the Origin200 chassis.
Grasp the handle of the peripheral carrier and pull the carrier out of the
5.25-inch drive bay.
Figure 8-6 Removing the Peripheral Carrier
