4. Slide the drive into the peripheral carrier and attach it with four screws through the
side of the carrier, as shown in Figure 2-12.
When installing the drive, be careful to keep track of its orientation in the
carrier so that you do not install the drive upside down.
Front
Figure 2-12 Inserting a 5.25-Inch Drive in the Peripheral Carrier
Putting the Pieces Together
45
