Chapter 5: Origin200 Cosmetic Features and Covers

Removing the System Cover and Chassis Access Door

118
Caution: Because of the weight of an Origin200 system, two people are required to lift
and move the chassis.
To remove the system cover and chassis access panel of an Origin200 server, follow these
steps:
1. Power off the system. See "Turning Off the System" on page 83.
2. Remove the system cover, as shown in Figure 5-5.
Using a #2 Phillips screwdriver, remove the two screws that secure the side
panel to the chassis.
Pull the rear edge of the side panel away from the rear of the system.
Slide the system cover back and off the system.
