xStack DGS-3200 Series Layer 2 Managed Gigabit Ethernet Switch Web UI Reference Guide
Click the Apply button to accept the changes made for each individual section.

SMTP Settings

SMTP or Simple Mail Transfer Protocol is a function of the Switch that will send switch events to mail recipients based on e-mail
addresses entered in the window below. The Switch is to be configured as a client of SMTP while the server is a remote device
that will receive messages from the Switch, place the appropriate information into an e-mail and deliver it to recipients configured
on the Switch. This can benefit the Switch administrator by simplifying the management of small workgroups or wiring closets,
increasing the speed of handling emergency Switch events, and enhancing security by recording questionable events occurring on
the Switch.
Users can set up the SMTP server for the Switch, along with setting e-mail addresses to which switch log files can be sent when a
problem arises on the Switch.
To view the following window, click Network Application > SMTP Settings:
The following parameters may be configured or viewed:
Parameter Description
SMTP State Use the radio button to enable or disable the SMTP service on this device.
SMTP Server Enter the IP address of the SMTP server on a remote device. This will be the device that sends
Address out the mail for you.
SMTP Server Port Enter the virtual port number that the Switch will connect with on the SMTP server. The common
(1-65535) port number for SMTP is 25, yet a value between 1 and 65535 can be chosen.
Self Mail Address Enter the e-mail address from which mail messages will be sent. This address will be the "from"
address on the e-mail message sent to a recipient. Only one self-mail address can be configured
for this Switch. This string can be no more that 64 alphanumeric characters.
Add A Mail Enter an e-mail address and click the Add button. Up to eight e-mail addresses can be added
Receiver per Switch. To delete these addresses from the Switch, click the corresponding Delete button in
the SMTP Mail Receiver Address table at the bottom of the window.
Click Apply to implement the changes.
MAC - The MAC address of the Switch will be used to encode the circuit ID option.
IP - The Switch's IP address will be used to encode the circuit ID option. This is the default.
UDF - A user specified string to be used to encode the circuit ID option. The maximum length
is 32.
Figure 8 - 22. SMTP Settings window
