xStack
DGS-3200 Series Layer 2 Managed Gigabit Ethernet Switch Web UI Reference Guide
The following parameters can be configured:
Parameter
VLAN Name
VLAN ID (2-4094)
VLAN List
Click Add to create the new Private VLAN entry. Click Find to search for the specific information entered. Click View All to see
all the entries. Click Edit to configure the specific entry. Click Delete to remove the specific entry.
Click Edit to see the following window.
The following parameters can be configured:
Parameter
Secondary VLAN Type
Figure 3 - 13. Private VLAN Settings window
Description
Click the radio button and enter the name of the private VLAN.
Specify the VLAN ID of the Private VLAN.
Specify a list of VLAN IDs.
Figure 3 - 14. Private VLAN Settings - Edit window
Description
Use the drop-down menu to specify the Secondary VLAN Type. The available options are
described below:
Isolated- An Isolated VLAN is a secondary VLAN whose distinctive characteristic is that all
hosts connected to its ports are isolated at Layer 2. The primary advantage of an isolated
VLAN is that it allows a Private VLAN to only use two VLAN identifiers to provide port
isolation and serve any number of end users. A Private VLAN can only support one
isolated VLAN.
63
