xStack DGS-3200 Series Layer 2 Managed Gigabit Ethernet Switch Web UI Reference Guide
State
Idle Time (1-1440)
Block Time (0-300)
Click Apply to implement changes made.

WAC Authenticating State

Users can display the current WAC authentication state and delete WAC authentication state settings.
To view the following window, click Security > Web-based Access Control (WAC) > WAC Authenticating State:
The following fields and settings can be viewed:
Parameter Description
Port List (e.g.: 1,
Enter a port or range of ports, and tick the appropriate check box(s), Authenticated,
5-10) Authenticating, and Blocked.
Authenticated
Tick this check box to display all authenticated users for a port.
Authenticating Tick this check box to display all authenticating users for a port.
Blocked Tick this check box to display all blocked users for a port.
Click the Find button to locate a specific entry based on the information entered. Click the Clear by Port button to remove entry
based on the port list entered. Click the View All Hosts button to display all the existing entries. Click the Clear All Hosts button
to remove all the entries listed.
WAC Customize Page
This window is used to customize the authenticate page elements.
To view the following window, click Security > Web-based Access Control (WAC) > WAC Customize Page:
authenticated state. Enter a value between 0 and 1440 minutes. A value of 0 indicates the
authenticated host will never age out on the port. The default value is 1440 minutes (24
hours). Tick the adjacent Infinite textbox to disable aging. The default value is infinite.
Use this drop-down menu to enable the configured ports as WAC ports.
If there is no traffic during the Idle Time parameter, the host will be moved back to the
unauthenticated state. Enter a value between 0 and 1440 minutes. A value of 0 indicates the
Idle state of the authenticated host on the port will never be checked. Tick the adjacent
Infinite textbox to disable the idle time. The default value is infinite.
This parameter is the period of time a host will be blocked if it fails to pass authentication.
Enter a value between 0 and 300 seconds. The default value is 30 seconds.
Figure 6 - 60. WAC Authentication State window
