The following parameters can be set:
Parameter
Port Security Trap/Log
Settings
From Port / To Port
Admin State
Max Learning Address
(0-64)
Lock Address Mode
Click Apply to implement changes made.

Port Lock Entries

Users can remove an entry from the port security entries learned by the Switch and entered into the forwarding database. This
function is only operable if the Mode in the Port Security Settings window is selected as Permanent or DeleteOnReset, or in
other words, only addresses that are statically learned by the Switch can be deleted.
To view the following window, click Security > Port Security > Port Lock Entries:
Figure 6 - 14. Port Security Settings window
Description
Use the radio button to enable or disable Port Security Traps and Log Settings on the
Switch.
Use the drop-down menu to select a range of ports to be configured.
This drop-down menu allows the user to enable or disable Port Security (locked MAC
address table for the selected ports).
The number of MAC addresses that will be in the MAC address forwarding table for the
selected switch and group of ports.
This drop-down menu allows the option of how the MAC address table locking will be
implemented on the Switch, for the selected group of ports. The options are:
Permanent – Unless users manually delete these secured addresses from the switch, the
locked addresses will never be aged out, even when the Switch is restarted.
DeleteOnTimeout – The locked addresses will age out after the aging timer expires.
DeleteOnReset – The locked addresses will not age out until the Switch has been reset or
rebooted.
