xStack
DGS-3200 Series Layer 2 Managed Gigabit Ethernet Switch Web UI Reference Guide
The following parameters can be configured:
Parameter
VLAN Name
VID
MAC Address
Port
Click Apply to implement the changes made. Click Clear All to remove all the information entered. Click All to select all ports.
Description
Click the radio button and enter the VLAN name of the NLB multicast FDB entry to be
created.
Click the radio button and enter the VLAN by the VLAN ID.
Enter the MAC address of the NLB multicast FDB entry to be created.
Choose the forwarding ports for the specified NLB multicast FDB entry.
None – The port is not the forwarding port.
Egress - The port is the forwarding port.
114
