xStack DGS-3200 Series Layer 2 Managed Gigabit Ethernet Switch Web UI Reference Guide
Click Apply to implement the new System Severity Settings.

MAC Address Aging Time

Users can configure the MAC Address aging time on the Switch.
To view the following window, click Configuration > MAC Address Aging Time:
The following parameter may be configured or viewed:
Parameter Description
MAC Address Specify the length of time a learned MAC Address will remain in the forwarding table without
Aging Time (10- being accessed (that is, how long a learned MAC Address is allowed to remain idle). To change
875) this, type in a different value to represent the MAC address age-out time in seconds. The MAC
Address Aging Time can be set to any value between 10 and 875 seconds. The default setting
is 300 seconds.
Click Apply to set the MAC Address Aging Time.

Web Settings

Users can configure the Web settings on the Switch.
To view the following window, click Configuration > Web Settings:
The following parameters may be configured or viewed:
Parameter Description
Web Status Web-based management is Enabled by default. If you choose to disable this by clicking
Disabled, you will lose the ability to configure the system through the web interface as soon as
these settings are applied.
Port (1-65535) The TCP port number used for Web-based management of the Switch. The "well-known" TCP
port for the Web protocol is 80.
Click Apply to set the web settings.
Severity Name. Select Critical to send only critical events to the Switch's log or SNMP agent.
Choose Warning to send critical and warning events to the Switch's log or SNMP agent.
Select Information to send informational, warning, and critical events to the Switch's log or
SNMP agent.
Figure 2 – 20. MAC Address Aging Time window
Figure 2 – 21. Web Settings window
