xStack DGS-3200 Series Layer 2 Managed Gigabit Ethernet Switch Web UI Reference Guide
To set the User Account settings for the JWAC by the Switch, complete the following fields and then click the Add button. To
clear the current JWAC user settings in the table at the bottom of the window, click the Delete All button.
Parameter
User Name
Password
Confirm Password
VID (1-4094)
Click the Add button to add a new entry based on the information entered. Click the Delete All button to remove all the entries
listed. Click the Edit button to re-configure the specific entry. Click the Delete button to remove the specific entry.

JWAC Authentication State

Users can display Japanese Web-based Access Control Host Table information.
To view the following window, click Security > Japanese Web-based Access Control (JWAC) > JWAC Authentication Sate:
The following fields and settings can be viewed:
Parameter Description
Port List Enter a port or range of ports.
Authenticated Tick this check box to only show authenticated client hosts.
Authenticating Tick this check box to only show client hosts in the authenticating process.
Blocked Tick this check box to only show client hosts being temporarily blocked because of the failure of
authentication.
Figure 6 - 64. JWAC User Settings window
Description
Enter a username of up to 15 alphanumeric characters.
Enter the password the administrator has chosen for the selected user. This field is case-
sensitive and must be a complete alphanumeric string.
Retype the password entered in the previous field.
Enter a VLAN ID number between 1 and 4094.
Figure 6 - 65. JWAC Authentication State window
184
