xStack DGS-3200 Series Layer 2 Managed Gigabit Ethernet Switch Web UI Reference Guide
The following parameters can be configured:
Parameter Description
User Name An alphanumeric string of up to 32 characters. This is used to identify the SNMP users.
Group Name This name is used to specify the SNMP group created can request SNMP messages.
SNMP Version V3 – Indicates that SNMP version 3 is in use.
SNMP V3 Use the drop-down menu to enable encryption for SNMP V3. This is only operable in SNMP V3
Encryption mode. The choices are None, Password, or Key.
Auth-Protocol MD5 – Specifies that the HMAC-MD5-96 authentication level will be used. This field is only
operable when V3 is selected in the SNMP Version field and the Encryption field has been
checked. This field will require the user to enter a password.
SHA – Specifies that the HMAC-SHA authentication protocol will be used. This field is only
operable when V3 is selected in the SNMP Version field and the Encryption field has been
checked. This field will require the user to enter a password.
Priv-Protocol None – Specifies that no authorization protocol is in use.
DES – Specifies that DES 56-bit encryption is in use, based on the CBC-DES (DES-56)
standard. This field is only operable when V3 is selected in the SNMP Version field and the
Encryption field has been checked. This field will require the user to enter a password between 8
and 16 alphanumeric characters.
To delete an existing SNMP User Table entry, click the Delete button corresponding to the entry to delete.
To implement changes made, click Apply.

SNMP Community Table

Users can create an SNMP community string to define the relationship between the SNMP manager and an agent. The community
string acts like a password to permit access to the agent on the Switch. One or more of the following characteristics can be
associated with the community string:
•
An Access List of IP addresses of SNMP managers that are permitted to use the community string to gain access to the
Switch's SNMP agent.
•
Any MIB view that defines the subset of all MIB objects will be accessible to the SNMP community.
•
Read/write or read-only level permission for the MIB objects accessible to the SNMP community.
To view the following window, click SNMP Settings > Configuration > SNMP Community Table:
Figure 2 - 39. SNMP User Table window
