  • Page 1 ® IntelliTouch Pool and Spa Control System User’s Guide IMPORTANT SAFETY INSTRUCTIONS READ AND FOLLOW ALL INSTRUCTIONS SAVE THESE INSTRUCTIONS...
  • Page 2 Pentair Water Pool and Spa, Inc. Those names and brands may...

  • Page 3: Table Of Contents

    Digital Wireless Tablet (iTC45 Kit - P/N 520503) ................... 5 IntelliTouch ScreenLogic Interface Accessory Kits ....................5 SECTION 2 - OPERATING THE INTELLITOUCH SYSTEM ................7 Main Screen (Indoor Control Panel and MobileTouch wireless control panel) ............7 IntelliTouch Menus ..............................8 IntelliTouch Indoor Control Panel Menus .......................
  • Page 4 Prepare the System for Operation ........................31 Checking the Main Load Center ........................31 Setting up the IntelliTouch System using the Indoor Control Panel or MobileTouch ........33 The Preference Screen Options ........................33 Set the System Clock ..........................34 Assigning Circuit Names (for Display 1, 2, 3, and 4) ..................
  • Page 5 Using the Service Personnel Screen ......................... 85 Checking Firmware Version ..........................85 Manually Updating Between Indoor and Outdoor Control Panels ..............86 Erasing the System Memory ..........................87 System Worksheet Overview ..........................88 IntelliTouch Pool and Spa Control System User’s Guide...
  • Page 6 Troubleshooting ..............................99 Frequently Asked Questions (FAQ) ........................99 What does a ‘+3’ IntelliTouch system mean? ....................99 How Do I Setup/Configure/Program the 2-Speed Pump? ................99 Can I turn the Heater On and Change the temperature from the Spa? ............99 How do I get Solar to switch on? ........................

  • Page 7: Important Warning And Safety Instructions

    WARNING - GAS HEATER: The IntelliTouch® automation control system is designed to supply high voltage (120 VAC / 240 VAC) to a gas heater and override the thermostat in the heater’s control circuit. This automation control system is intended to control gas heaters with a high temperature limit switch(s) safety circuit ONLY.
  • Page 8 Consult the dealer or an experienced radio/TV technician for help. General Installation Information 1. All work on the IntelliTouch® load/power center must be performed by a licensed electrician, and must conform to all national, state, and local codes. 2. Install to provide drainage of compartment for electrical components.
  • Page 9 Blank Page IntelliTouch Pool and Spa Control System User’s Guide...

  • Page 10: In This User's Guide

    This User’s Guide describes how to operate the IntelliTouch ® pool and spa control system. Using the IntelliTouch indoor or wireless control panel you can control daily pool and spa filtering schedules, water temperature control, heater and light functions. This manual consists of the following sections:...

  • Page 11: Section 1 - Intellitouch System Overview

    Optional controllers are also available such as the wireless digital tablet and the in-wall touch screen that can interface with your PC. IntelliTouch is a scalable system that can be upgraded to a completely integrated home automation solution including audio, security, climate, irrigation and more.

  • Page 12: Intellitouch System Components

    IntelliTouch System Components The main required components of an IntelliTouch system is a Load Center or Power Center, IntelliTouch Personality Kit, and Interface: Load or Power Center • Load Center: Provides a larger footprint (17" W x 23" H) Includes built-in sub panel (150 AMPS) capable of holding up to eight 1”...

  • Page 13: Intellitouch Interfaces

    Kit (P/N 520500) – Includes Protocol Interface Adapter and wireless router that connects to existing Desktop or Laptop PC. This allows control of IntelliTouch pool and spa systems via PC (requires PC with an Ethernet connection, and Windows XP operating system).

  • Page 14: Intellitouch In Your Home

    IntelliTouch in and around your home Personal Computer (PC): Existing home owner’s PC or Laptop. Connects to a wireless router and the IntelliTouch Protocol adapter for control of IntelliTouch pool/spa systems. Requires a PC/Laptop (Windows XP) with Ethernet/ RJ45 adapter installed.

  • Page 15: Intellitouch Interface Kits

    IntelliTouch ScreenLogic Interface Accessory Kits Up to a total of four ScreenLogic interfaces can be used with an IntelliTouch system, as shown above. If you need additional interfaces, first order one of the ScreenLogic interface kits, then order one or more of the following accessory interfaces accessory kits: •...
  • Page 16 Blank Page IntelliTouch Pool and Spa Control System User’s Guide...

  • Page 17: Section 2 - Operating The Intellitouch System

    Feature Circuit screen. Use "Feature" circuits to - Press the DISPLAY assign additional circuits button to toggle to controll valve actuators between screens. for water features, spa spillway, 2-speed pump, and macro circuits. IntelliTouch Pool and Spa Control System User’s Guide...

  • Page 18: Intellitouch Menus

    Setup control panel features, PREFERENCE backlight, beep etc. (page 33) ADVANCED Setup circuit names, functions, CIRCUIT MACROS configure valves (pages 34-41) MENU/SETUP BACK EXIT Setup MACRO circuit functions (page 79) SETUP menus IntelliTouch Pool and Spa Control System User’s Guide...

  • Page 19: Intellitouch Indoor Control Panel Menus

    INTELLICHEM - Pg. 73 SPA OPTIONS -Pg. 77 DEGREES C/F - Pg. 77 35-36 MAGIC STREAM KEYPAD LOCK Pg. 83 THUMPER - TOGGLE RESET - HOLD / STOP Also see page 42 IntelliTouch Pool and Spa Control System User’s Guide...

  • Page 20: Heating Your Spa And Pool

    Press to lower SPA temperature Press to increase SPA temperature Hi-Temp Mode for i5S and i9+3S Press to increase POOL temperature Press to lower POOL temperature Hi-Temp Mode for i5S and i9+3S Back button Set button IntelliTouch Pool and Spa Control System User’s Guide...

  • Page 21: Selecting The Heating System

    (off) in the Heat menu. The optional iS10 Spa-Side remote, iS4 Spa Side remote or QuickTouch QT4 wireless remote can be used to switch the heater on. The IntelliTouch system supports gas, electric and solar heating systems. IntelliTouch will use the heating source that is selected. Multiple heaters are supported.

  • Page 22: Switching On Lights Manually

    Note: Use the SYNC button to switch ON all IntelliBrite, ® MagicStream laminar lights, SAm, SAL, or FIBERworks color changing lights to synchronize their colors when using the “Color Swim” lighting feature. IntelliTouch Pool and Spa Control System User’s Guide...

  • Page 23: Special Lighting Features

    LIGHTS Use the ALL OFF button SAVE ALL ON ALL OFF SYNC Switch on all color changing lights to synchronize colors Switches all SAm, SAL and Fiberworks lights ON and Synchronizes lights IntelliTouch Pool and Spa Control System User’s Guide...

  • Page 24: Dimming Lights

    Spa or Pool button to switch the circuit on. From the “Program” screen, you can schedule IntelliTouch to automatically run equipment like pool filtration or lights. Any circuit (auxiliary, feature, or macro) can be scheduled to switch on and off at a specific time and on a any day(s) of the week.

  • Page 25: Smart Start (Setting Up Sam, Sal And Intellibrite Lights)

    SS_Yes and SS_No. Select SS_Yes to automatically begin changing colors when the light circuit is switch on. 4. Setup each light circuit as described above in steps 2 - 5. IntelliTouch Pool and Spa Control System User’s Guide...

  • Page 26: Using The Once Only Timer

    Using the Once Only Timer The “Once Only” programming feature enables IntelliTouch to automatically switch equipment on for one time only. For example, you can set to have the spa and heater switch on before you get home from work for one evening.

  • Page 27: Setting The Egg Timer Function

    (1) program for the selected circuit. 7. Press the Back button to return to the SPA, POOL and AUX equipment selection screen to program other equipment. 8. Press the Exit button to return to the main screen. IntelliTouch Pool and Spa Control System User’s Guide...

  • Page 28: Is10 Spa-Side Remote Controller

    The iS10 Spa- Side remote controller is listed UL (1563) for use with the IntelliTouch systems at the water’s edge. Five (5) in- line buttons control up to ten (10) system functions numbered one through five from left to right as shown (if the system allows).

  • Page 29: Is4 Spa-Side Remote Controller

    300 ft. from the MobileTouch transceiver antenna (line of sight) which is typically located near the IntelliTouch load center. The optimum wireless transmit and receive range may be affected by physical obstructions, (especially those containing metal), weather conditions, and geographical features.

  • Page 30: Charging The Mobiletouch Wireless Controller

    The range of the MobileTouch wireless controller can be up to 300 feet from its transceiver antenna (line of sight). The transceiver antenna is typically located outside near the IntelliTouch Load Center. The device can be used all day at full power with a complete battery charge (3 to 4 hours).

  • Page 31: Quicktouch Wireless Qt4 Remote Controller

    15 blades (three terminal and twelve bi-polar blades). IntelliChlor “dummy” bypass cell (P/N 520588): Recommended for new pool start-up. Note: For IntelliChlor setup information, see “Chlorine Generator,” on page 54. IntelliTouch Pool and Spa Control System User’s Guide...

  • Page 32: Intelliflo Vf 3050 Variable Flow Pump (Accessory)

    The IntelliFlo VSF+SVRS variable speed and frequency (RPM/GPM) pump offers the same basic feature set as the IntelliFlo VS 3050 pump with additional Safety Vacuum Release System (SVRS) and flow control (GPM) functionality. Note: For IntelliFlo VSF+SVRS setup information, see page 65. IntelliFlo pump IntelliTouch Pool and Spa Control System User’s Guide...

  • Page 33: Section 3 - Preparing The System For Initial Start-Up

    Section 3 Preparing the System for Initial Start-up Setting up the IntelliTouch System Use the following recommended steps to configure the IntelliTouch system using the Indoor Control Panel or MobileTouch wireless controller. 1. Main screen preference settings (page 33) Setup the Indoor Control Panel main screen. Set the system clock and what circuit names you wish to display on the main screen.
  • Page 34 7. Setting up additional equipment (pages 53) Configure the IntelliTouch system what special equipment the system may have installed. • Is there an IntelliFlo pump installed? • Is there an UltraTemp® heat pump installed? • Is there an IntelliChlor salt chlorine generator installed? •...

  • Page 35: Wired Controllers (Automatically Enabled)

    Wired Controllers (Automatically Enabled) When powered up for the first time, the IntelliTouch system will automatically enable one each of the following wired controllers: • Outdoor Control Panel (located in the main Load Center or Power Center) • Indoor Control Panel (wired to the Personality board in Load Center). Note: Additional Indoor Control Panels must be manually assignment.

  • Page 36: Manually Enabling Expansion Centers

    Note: For information about how the IntelliTouch automatically enables wired controllers, refer to the “Automatically Enabled Wired Controllers,’’ page 25. Up to three (3) additional Expansion Centers can be installed in the IntelliTouch system. The IntelliTouch system automatically assigns the “main” Load Center or Power Center as number 1, and other additional Expansion Centers as number 2, 3, or 4.

  • Page 37: Assigning Additional Expansion Centers

    Number 4 Note: Expansion Centers may be a Load Center or Power Center. Connections from the Main Load Center to an Expansion Center is via the COM port on the Personality board. IntelliTouch Pool and Spa Control System User’s Guide...

  • Page 38: Setting Up The Mobiletouch Wireless Controller

    2 and 4 at the same time. The Service Personnel screen will be displayed. Press button 2 and 4 at the same time to access the Service Personnel screen IntelliTouch Pool and Spa Control System User’s Guide...
  • Page 39 SAVE, you will return back to the prior screen. Press the RESET button on the outdoor control panel and you MobileTouch is ready to use. If the MobileTouch is not connecting check your wiring connections. 7. After selecting “Lock On Address” the MobileTouch controller is now ready to operate the IntelliTouch system. The “Service Personnel” screen will be displayed.

  • Page 40: Adding An Is10 Spa-Side Remote Controller

    IS1. Other additional iS10 remotes need to be manually assigned. To assign additional iS10 remotes as iS2, iS3, or iS4: 1. On the IntelliTouch Outdoor Control Panel, press the Reset button, then press the 1 button. The three (3) System Control LEDs will start flashing.

  • Page 41: Prepare The System For Operation

    Note: for i5+3, i7+3, or i9+3 systems, go to step 5. If you are working with the i5S+3, i9+3S, or i10+3D systems, skip step 5 and go to step 6. The IntelliTouch system model ID is located on the front of the Indoor Control Panel below the low voltage circuit breakers.
  • Page 42 For details about adding multiple Expansion Centers and controllers, see “Assigning Additional Expansion Centers” on page 27. V” Valve button ‘ “F” Filter Pump button AUX circuits buttons/LEDs IntelliTouch system model number Label location for AUX circuit name IntelliTouch Pool and Spa Control System User’s Guide...

  • Page 43: Setting Up The Intellitouch System Using The Indoor Control Panel Or Mobiletouch

    Setting up the IntelliTouch System using the Indoor Control Panel or MobileTouch The following describes how to configure and set up the IntelliTouch system using the Indoor Control Panel or MobileTouch wireless control panel. The Preference Screen Options From the Preference screen you can change various screen options.

  • Page 44: Set The System Clock

    Set the System Clock It’s important to set the IntelliTouch system clock to the current time and date to ensure all automatic pool functions to work correctly. Getting There MENU SETUP CLOCK To set the system clock, go to the Clock screen.

  • Page 45: Selecting Display Screen 1, 2, 3, Or 4

    3. Use the Up and Down buttons at the bottom of the screen to scroll through the alphabetical list of preset equipment names. Choose the equipment name that matches the label name for button number 1 on the Load Center Outdoor Control Panel. IntelliTouch Pool and Spa Control System User’s Guide...

  • Page 46: Selecting The Display Screens

    7. ALL LIGHTS EDGE PUMP CLEANERS WATER FALL MON 4:32AM AIR TEMP 92˚ DISPLAY MENU HEAT LIGHTS Display button Main screen Display #1, #2, #3, or #4 screen Feature circuits screen IntelliTouch Pool and Spa Control System User’s Guide...

  • Page 47: Intellitouch Circuit Names

    FOUNTAIN FOUNTAIN 1 FOUNTAIN 2 FOUNTAIN 3 FOUNTAINS FRONT LIGHT GARDEN LTS GAZEBO LTS HIGH SPEED HIGH TEMP HOUSE LIGHT JETS LIGHTS LOW SPEED LOW TEMP MALIBU LTS MIST MOTOR VALVE MUSIC IntelliTouch Pool and Spa Control System User’s Guide...

  • Page 48: Creating Custom Names For Auxiliary Circuits

    Move cursor right Scroll forward through characters Scroll back through characters Move cursor up Move cursor down Move cursor left Move cursor right Delete and Backspace button Select button Display Clear button button IntelliTouch Pool and Spa Control System User’s Guide...

  • Page 49: Assign Circuit Functions And Freeze Protection

    Select the Feature circuit name to assign a function to it. Use this MON 4:32AM AIR TEMP 92˚ MENU HEAT LIGHTS DISPLAY button to toggle between the Feature circuit screen and the Circuit screen. IntelliTouch Pool and Spa Control System User’s Guide...
  • Page 50 5. Press the BACK button to return to the Circuits screen and repeat steps 1 through 4 to assign functions to other circuits. 6. Press EXIT button to return to the Main screen. IntelliTouch Pool and Spa Control System User’s Guide...

  • Page 51: Special Functions For Circuits

    “GENERIC” circuit function, not the “Floor Cleaner” function. Assigning the “Generic” circuit function ensures that the pump will not ramp up and down every 20 minutes. IntelliTouch Pool and Spa Control System User’s Guide...

  • Page 52: Setting Up Lighting Options (Color Swim And Color Set)

    The light circuit name will appear on the main screen. Each light (SAM or SAL) must also be assigned a circuit function. If the circuit function has been assigned, start at Step 5 (see next page). IntelliTouch Pool and Spa Control System User’s Guide...
  • Page 53 7. Press the button next to DISPLAY 1. Display 1 is the main indoor control panel. If there are additional IntelliTouch Expansion Centers installed, Display 2, Display 3, and Display 4 will be displayed. Select which indoor control panel to configure. From this screen you can also configure Feature circuits.
  • Page 54 Press this button to configure “Pool Sam 1” light circuit for “SPA” POOL SAM 1 NONE Available light circuit for “POOL” NONE NONE View/configure next NEXT GROUP six light circuits LIGHTS/CONFIG-SELECTION BACK EXIT IntelliTouch Pool and Spa Control System User’s Guide...
  • Page 55 LIGHTS SAVE ALL ON ALL OFF SYNC 19. Press Back to view the Lights screen. “SPA SAL” on and off switch is now assigned to the AUX 1 button. IntelliTouch Pool and Spa Control System User’s Guide...

  • Page 56: Setting Up Intellibrite Led Lights

    3. Press the SAVE button on the bottom of the screen. Press MENU/SETUP/ADV/FUNC/AUX 1 the EXIT button to return to the main screen. BACK SAVE EXIT 4. Proceed to Step 5. IntelliTouch Pool and Spa Control System User’s Guide...
  • Page 57 Select the color PREV WHITE NEXT Select the light position PREV 1ST POSITION NEXT Color Swim: Set the PREV DELAY 5 SECS NEXT delay time between lights LIGHTS/CONFIG/POOL SAM 1 SAVE EXIT IntelliTouch Pool and Spa Control System User’s Guide...

  • Page 58: Selecting Intellibrite Modes

    (6) seconds followed by the “COLOR SWIM” feature selection. If the light was previously on, after pressing the SWIM button, the previously selected color will momentarily illuminate, no illumination will occur for approximately six (6) seconds followed by the “COLOR SWIM” feature selection. IntelliTouch Pool and Spa Control System User’s Guide...

  • Page 59: Feature: Color Set

    Use the “Hold” and “Recall” feature to capture and save the selected color and recall it at a later time. Note: After pressing the HOLD or RECALL button, no illumination will occur for up to 10 seconds, then a white light will momentarily illuminate, followed by the saved color. IntelliTouch Pool and Spa Control System User’s Guide...

  • Page 60: Setting Up Magicstream Laminars

    AUX 4 MAGICSTREAM NEXT PREV AUX 1 AUX 5 ON WITH FREEZE AUX 3 AUX 6 AUX 2 AUX 7 AUX 4 AUX 8 MENU/SETUP/ADV/FUNC/AUX 1 MENU/SETUP/ADV/FUNCTION/SELECT BACK SAVE EXIT BACK EXIT IntelliTouch Pool and Spa Control System User’s Guide...
  • Page 61 INTELLIBRITE MAGICSTREAM NEXT GROUP CONFIGURE button for Color and laminar Mode Light LIGHTS features show SAVE ALL ON ALL OFF SYNC screen Lights screen using IntelliBrite lights and MagicStream laminars IntelliTouch Pool and Spa Control System User’s Guide...

  • Page 62: Using The Magicstream Laminar Features

    HOLD / STOP POOL LIGHT POOL LAMINAR 2 RESET MagicStream INTELLIBRITE MAGICSTREAM NEXT GROUP CONFIGURE button for laminar LIGHTS LIGHTS/MAGICSTREAM features EXIT SAVE ALL ON ALL OFF SYNC BACK screen IntelliTouch Pool and Spa Control System User’s Guide...

  • Page 63: Setting Up Equipment (From The Equipment Screen)

    Setting up Equipment (from the Equipment Screen) If any special equipment is attached the IntelliTouch Load Center, you need to setup IntelliTouch to recognize that equipment. From the Equipment screen PRIORITY SOLAR you can setup: CHLORINATOR 2-SPEED PMP INTELLIFLO PUMP DELAYS •...

  • Page 64: Chlorine Generator

    Note: Call your manufacturer for compatibility with IntelliTouch systems. Activating the Chlorinator For IntelliTouch to control and operate the chlorinator, first enable the chlorinator from the IntelliTouch Indoor Control Panel. If the chlorinator control is enabled, the controls on the chlorinator are disabled and can only be operated by IntelliTouch.

  • Page 65: Super Chlorinate The Pool Water

    6. Press Exit to return to the main screen. Note: For information about wiring a salt chlorine generator MODEL NAME HERE to the IntelliTouch system , see “Wiring IntelliTouch to a Salt STATUS OK - NO ERRORS Chlorine Generator,” on page 112.

  • Page 66: Intelliflo Vf 3050, Vs 3050 And Vsf+Svrs Pump Setup

    Assigning an IntelliFlo VF 3050 pump address Before assigning a pump address in the IntelliTouch indoor control panel, first set the address on the pump itself. If there is only one pump, it is always seen as pump #1 by IntelliTouch. In this ®...

  • Page 67: Intelliflo Menu Options

    IntelliTouch requires a bit more delay since the circulation pump may be on any address, e.g. #5, if there are four IntelliFlo VS pumps at 1 -4, and a VF at #5. So by default no pump is assigned. When you go into the menu “Circuit Functions”...

  • Page 68: Intelliflo Vf 3050 Pump Setup

    . The main pump screen displays IntelliFlo #2 with the assigned circuit name. INTELLIFLO Select another IntelliFlo pump and repeat step 3 to assign a circuit name. 5. When finished, press the BACK button to return to the Equipment screen. IntelliTouch Pool and Spa Control System User’s Guide...

  • Page 69: Filtering Parameters

    To , e l exit, press the EXIT button to return to the Equipment screen. l l e O ‘ i t ’ t l i f IntelliTouch Pool and Spa Control System User’s Guide...

  • Page 70: Priming Parameters

    S “ ” e h t i l l i f n i i n i Save . e l button IntelliTouch Pool and Spa Control System User’s Guide...

  • Page 71: Backwash Parameters

    “Clean Filter” pressure, IntelliTouch displays an alert message. This means that the filter must be cleaned (backwashed) to reduce the pressure. To do this, the pump must be stopped and the IntelliTouch outdoor control panel must be in “Service” mode (press the Auto button and select “Service” mode. To start the backwash flow operation, press the Start/Stop button on IntelliFlo, then press the Backwash button.

  • Page 72: Vacuum Parameters

    (Continued) Vacuum parameters Use the Vacuum mode to clean the pool manually. To operate the pump in Vacuum mode, place the IntelliTouch outdoor control panel in “Service Mode,” and stop the IntelliFlo pump. The pool service person can then press the Vacuum button on the IntelliFlo pump.

  • Page 73: Assign Custom Flows

    0 GPM Press this button NONE 0 GPM go to four NEXT PAGE additional circuits/ GPM settings MENU/SETP/EQUIP/INTELLIFLO/ASSIGN BACK SAVE PREV EXIT Save button Prev and Next buttons (use to adjust pump speed) IntelliTouch Pool and Spa Control System User’s Guide...

  • Page 74: Intelliflo Status Screen

    Displays the current filter status in percentage value. The higher the percent value the nearer the filter will require a backwash and rinse cycle. See ""Backwash Mode"" on page 61 for more information. Communication Status: Displays the IntelliFlo operating status IntelliTouch Pool and Spa Control System User’s Guide...

  • Page 75: Intelliflo Vs 3050 And Vsf+Svrs Pump Setup

    Before assigning a pump address in the IntelliTouch indoor control panel, first set the address on the pump itself. If there is only one pump, it is always seen as pump #1 by IntelliTouch. In this case you do not need to set the pump address.

  • Page 76: Setting Up An Intelliflo Vs 3050 And Vsf+Svrs Pump From Equipment Screen

    IntelliTouch “Equipment” screen. When using a single IntelliFlo VS 3050 or VSF +SVRS pump for remote control with IntelliTouch, the default address is always pump #1. When using multiple IntelliFlo VS 3050 and VSF +SVRS pumps with IntelliTouch assign an address to each pump.

  • Page 77: Priming Parameters (Intelliflo Vs 3050)

    BACK NEXT 4. Press the lower SAVE button to save the settings. 5. Press the EXIT button to return to the Equipment screen. Press EXIT again to return to the main screen. IntelliTouch Pool and Spa Control System User’s Guide...

  • Page 78: Assign Custom Speeds (Rpm) Intelliflo Vs 3050)

    If you need additional pump speed circuits, press the button next to NEXT PAGE to access an additional four circuits, then repeat step 3. 5. When finished, press the BACK button to return to the Equipment screen. IntelliTouch Pool and Spa Control System User’s Guide...

  • Page 79: Assign Custom Speeds (Rpm/Gpm) Intelliflo Vsf+Svrs

    AUX 6 2350 RPM Press this NONE 30 GPM NEXT PAGE RPM /GPM/PSI button to MENU/SETP/EQUIP/INTELLIFLO/ASSIGN assign a BACK PREV NEXT circuit name Prev and Next buttons (use to assign a circuit name) IntelliTouch Pool and Spa Control System User’s Guide...
  • Page 80 DISABLE PSI change RPM button (1-30) to GPM BACK BACK DOWN ENABLE (or SAVE setting Disable) PSI setting 9. When finished, press the BACK button three times to return to the Equipment screen. IntelliTouch Pool and Spa Control System User’s Guide...

  • Page 81: Intelliflo Vs 3050 And Intelliflo Vsf+Svrs4 Status Screen

    Filter mode and flow control further assists in cost saving by always allowing the pump to do the least amount of work at all times. Communication Status: Displays the pump communication and operating status. IntelliTouch Pool and Spa Control System User’s Guide...

  • Page 82: Setting Up An Ultratemp Heat Pump

    Connection from the Pentair UltraTemp heat pump to the IntelliTouch system is via an RS-485 communication cable to a COM PORT on the IntelliTouch Personality circuit board. See page 112 for UltraTemp to IntelliTouch COM port wiring information.

  • Page 83: Setting Up Intellichem Water Chemistry Controller

    Setting up IntelliChem Water Chemistry Controller IntelliChem screen IntelliChem provides the IntelliTouch system with continual analysis of your swimming pool water sanitation and pH levels, providing real-time status information to dispense the proper amount of muriatic acid (pH reducer) and chlorine or bromine for the correct sanitization and pH balance. IntelliChem operates with or without a salt chlorine generator to provide a self-replenishing supply of chlorine generated from salt.

  • Page 84: Setup Solar Equipment And Heat Pump Option

    The air temperature is detected by the solar temperature sensor Press to scroll located on the IntelliTouch load center. The air temperature is through SPA and select not adjustable.

  • Page 85: Setting Up A 2-Speed Pump

    Some heater models require this cool down period or damage will occur. This is sometime referred to as the “Fireman Switch.” for example, If you are in the spa, and you switch it off. The IntelliTouch will return the valves to “Pool”...

  • Page 86: Delay Cancel Feature

    For convenience, on a one time basis, the DELAY CANCEL feature will cancel the following safety delays which can be set up in the IntelliTouch system. Please note there is generally not a need to cancel any of these delays except for servicing or testing the system.

  • Page 87: Spa Options

    1. Press the left or right side button next to Degrees Displayed In to select C (Celsius) or F (Fahrenheit). 2. Press the Save button. 3. Press the Exit button to return to the main screen. IntelliTouch Pool and Spa Control System User’s Guide...

  • Page 88: Configuring Valve Actuators (Controlled By Aux Or Feature Circuit)

    Configuring Valve Actuators (Controlled by AUX or Feature Circuit) All IntelliTouch systems can drive two auxiliary valve actuators (A and B) for applications such as solar heating and water features. With the addition of the Valve Module (P/N 520285), installed in the Load Center or Power Center, the system will accommodate up to three additional actuators (C, D, and E).

  • Page 89: Feature Circuits

    Feature circuit screen is displayed. The F icon located in WATER FALL the middle lower part of the screen indicates that Feature circuits screen is MON 4:32AM AIR TEMP 92˚ selected. MENU HEAT LIGHTS DISPLAY Feature circuits screen IntelliTouch Pool and Spa Control System User’s Guide...

  • Page 90: Creating A Macro Circuit

    Macro circuit can be assign to one button to switch on the spa, spa light, fountain, fountain light, and patio lights. The Macro circuit name (or custom name) can be added to the main list of “IntelliTouch circuit names”...

  • Page 91: Configuring Remote Control Button Circuits (Is4, Is10, Spacommand, Spa Side Remtoe, Qt4 Quicktouch, And Phone Remote)

    IntelliFlo VF 3050, VS 3050 and VSF+SVRS pump speeds. Up to two iS4 remotes, and four iS10 and SpaCommand remotes can be connected to an IntelliTouch system. To assign a circuits to spa-side remote buttons: iS4 spa side remote 1. Press the button next to CONFIGURE iS4’S or...

  • Page 92: Setting Up The Remote Control Telephone Feature

    HEAT.” This allows the heater to always switch on whenever the spa is switched on via the telephone. For more information, see page 77. 4. Press the Save button to save the setting and return to the remotes screen. 5. Press the Exit button. IntelliTouch Pool and Spa Control System User’s Guide...

  • Page 93: Disable/Enable Is10, Spacommand And Is4 Spa-Side Remote

    2. Press the Back button to return to the main screen. Keypad Lock If required, the IntelliTouch indoor control panel and MobileTouch wireless control panel can be passcode protected so that system settings and operations cannot be accessed. To access a ‘locked”...

  • Page 94: Section 4 - Service And Maintenance

    Service and Maintenance Calibrating Temperature Sensors The IntelliTouch system includes two temperature sensors (10 kΩ) for water and ambient air temperature. You can add a third sensor for controlling solar heating systems. Note: The i10+3D system includes three sensors. Generally, these sensors are accurate and you do not have to calibrate them. However, long plumbing runs and water features cause temperatures at a body of water to be different from the temperature sensor reading.

  • Page 95: Using The Service Personnel Screen

    This feature is available from the Service Personnel screen. Checking Firmware Version The IntelliTouch factory installed operating system software is known as firmware. There is a different firmware program loaded on the controllers (indoor control panel and MobileTouch) and the outdoor control panels.

  • Page 96: Manually Updating Between Indoor And Outdoor Control Panels

    Manually Updating Between Indoor and Outdoor Control Panels When the IntelliTouch system configuration settings are changed, or a new component is added, the updated information is automatically communicated to all of the control panels. Configuration settings reside in all the controllers and the outdoor control panel.

  • Page 97: Erasing The System Memory

    Erasing the System Memory IntelliTouch system circuit settings, equipment setup configuration information and screen display information is stored in the main Outdoor Control Panel and the Indoor Control Panel and MobileTouch wireless control panel. The current system configuration information automatically downloads from programmed control panels to update non-programmed control panels in case of accidental memory loss.

  • Page 98: System Worksheet Overview

    Spa-Side remote. The top buttons of the main screen are dedicated for Spa and Pool modes, however the lower buttons numbered downward may be configured to display any circuit. Note: Keep the homeowner worksheets for future reference. IntelliTouch Pool and Spa Control System User’s Guide...
  • Page 99 WORKSHEET FOR SHARED EQUIPMENT SYSTEMS i5+3, i7+3, i9+3 (Sheet 1 of 2) IntelliTouch Pool and Spa Control System User’s Guide...
  • Page 100 WORKSHEET FOR SHARED EQUIPMENT SYSTEMS i5+3, i7+3, i9+3 (Sheet 2 of 2) IntelliTouch Pool and Spa Control System User’s Guide...
  • Page 101 WORKSHEET FOR SINGLE BODY SYSTEMS i5S+3, i9+3S (Sheet 1 of 2) IntelliTouch Pool and Spa Control System User’s Guide...
  • Page 102 WORKSHEET FOR SINGLE BODY SYSTEMS i5S+3, i9+3S (Sheet 2 of 2) IntelliTouch Pool and Spa Control System User’s Guide...
  • Page 103 WORKSHEET FOR DUAL EQUIPMENT SYSTEMS i10+3D (Sheet 1 of 2) IntelliTouch Pool and Spa Control System User’s Guide...
  • Page 104 WORKSHEET FOR DUAL EQUIPMENT SYSTEMS i10+3D (Sheet 2 of 2) IntelliTouch Pool and Spa Control System User’s Guide...

  • Page 105: Main Outdoor Control Panel

    Load Center or Power Center. The Outdoor Control Panel includes, control buttons for pumps, filters, and heater, red status lights, and a Reset button. The IntelliTouch Personality board defines the type of equipment installed. The Outdoor Control Panel can be used to override the Indoor Control Panel functions for pool service and for equipment set up.

  • Page 106: Single Body Systems Model I5S+3, I9+3S

    Expansion Centers provide additional valve and auxiliary circuits. They are designed to operate with base systems: i9+3, i9+3S, i10+3D. The “Auxiliary circuit control capability” buttons operate the same way as on the main base Outdoor Control Panel. IntelliTouch Pool and Spa Control System User’s Guide...

  • Page 107: Erasing Outdoor Contrl Panel Memory (Factory Default)

    “AUTO” and “POOL” modes before resuming operation. 7 button Reset button LEDs (System Control) (i5, i10x) 5 button (i5+3, i7+3, i9+3, i5S+3, i9+3S, i10+3D) Main Outdoor Control Panel (Located in the Load Center or Power Center) IntelliTouch Pool and Spa Control System User’s Guide...

  • Page 108: Section 5 - Troubleshooting

    The following information describes a basic system start-up procedure. Before switching on the power to the IntelliTouch load center, first affix the auxiliary relay labels to the appropriate buttons on the Outdoor Control Panel. If necessary, write the function on the control panel.

  • Page 109: Troubleshooting

    This section provides information to help you resolve any problems that may occur during installing or using the IntelliTouch system. If by following the recommended actions you are still unable to resolve the problems please contact Technical Support, see page vii.

  • Page 110: What Are Color Swim And Color Set

    5. The procedure is identical to Step 2 above. Plug into the COM port on the Personality board in the Load Center or Power Center. Again, several different things may happen. Check all the relevant sections to avoid any problems. IntelliTouch Pool and Spa Control System User’s Guide...

  • Page 111: Fixing Mismatched System Personalities

    2. A controller’s memory is erased while unplugged from the system. 3. The IntelliTouch system personality (i9+3, i10+3D etc.) was changed. If this problem occurs a mismatched system personality message screen may be displayed. Press the NEXT button to update the controller to match the system personality. If you do not want to update the controller (most likely because you are service person using the controller for another purpose) then press IGNORE.

  • Page 112: System Problem Diagnosis

    . l e . l e l l o . l e h t i p i t / s l l l a f i d . l e IntelliTouch Pool and Spa Control System User’s Guide...

  • Page 113: Problem: Indoor And Outdoor Control Panels Work, But Is4 Fails To Operate

    - t l i t c f i . t i n l i t IntelliTouch Pool and Spa Control System User’s Guide...

  • Page 114: Problem: Indoor And Outdoor Control Panels Work, But Is10 Fails To Operate

    - t l i t c f i . l l i t IntelliTouch Pool and Spa Control System User’s Guide...

  • Page 115: Problem: The Mobile Control Panel Will Not Work, Or Will Not Work Dependably

    . t r h t i n i l o i t i t c o i t IntelliTouch Pool and Spa Control System User’s Guide...

  • Page 116: Problem: The Quick Touch Remote Will Not Work, Or Will Not Work Dependably

    . t r y f i s t i & , s t s t i s l i s l i t t i IntelliTouch Pool and Spa Control System User’s Guide...
  • Page 117 . r e y l t . r e y l t r e t e t t r e t e t t i l i o i r i t c IntelliTouch Pool and Spa Control System User’s Guide...

  • Page 118: Intelliflo Alerts And Warnings

    Manual modes. Note: The IntelliFlo's internal anti-freeze protection is disabled when connected to an IntelliTouch system. Freeze protection is provided by selecting YES at the ON WITH FREEZE portion of the IntelliTouch's appropriate circuit function menu. To re-enable the IntelliFlo's internal anti-freeze protection, the power to the drive must be cycled off then back on.

  • Page 119: Intelliflo Vs 3050 And Intelliflo Vsf+Svrs Warning And Alarm Conditions

    . y l v i r a t l r a l a t l i r d c t i t l o i r d t l o IntelliTouch Pool and Spa Control System User’s Guide...

  • Page 120: Intellitouch Power Center Wiring Diagram

    Power Center System Wiring Diagram IntelliTouch Pool and Spa Control System User’s Guide eu i...

  • Page 121: Intellitouch Load Center Wiring Diagram

    QP, QT, QPF, QE, Load Center System Wiring Diagram IntelliTouch Pool and Spa Control System User’s Guide...

  • Page 122: Wiring Intellitouch To A Salt Chlorine Generator

    IMPORTANT: On the UltraTemp AutoSet board ONLY CONNECT PIN 3 (YELLOW) and PIN 2 (GREEN) to the IntelliTouch COM port pins YELLOW and GREEN respectively. Do not connect pin 1 or pin 4 on the AutoSet board or the IntelliTouch Personality board. These pins are not used.

  • Page 123: Glossary

    GFCI. House Address: Signal that allows Each IntelliTouch system the ability to group all its attached components under a single system identification; prevents the system from confusing its components from components on a neighbor’s system.
  • Page 124 Transceiver: Special printed circuit board that can send and receive radio frequency (wireless) transmissions. QuickTouch QT4: Provides switching of up to four remote control circuits from a wireless Hand-held Remote. Valve Module: Accessory PCB (P/N 520285) to increase auxiliary actuator outputs from two to five. IntelliTouch Pool and Spa Control System User’s Guide...

  • Page 125: How To Backwash Your Filter

    To BACKWASH a sand filter with a multiport valve Note: If you are using an IntelliFlo pump with IntelliTouch, first set IntelliTouch in “SERVICE” mode (press the “System Control” button adn select “Service” on the IntelliTouch outdoor control panel.
  • Page 126 *520102* P/N 520102 Rev. J...

This manual is also suitable for:

Pool and spa control system

Table of Contents
