COMBI 2.2: Ed–Ctrl
Here you can set the Combination mode functions of the B-
mode functions of REALTIME CONTROLS knobs [1]–[4],
and [SW1] key, [SW2] key.
2.2–1: Ctrls
(Controls)
2.2–1a
2.2–1a: Knob B Assign
These settings assign functions (mainly various control
changes) to the B-mode of the REALTIME CONTROLS
knobs [1]–[4] (☞p.225 "Realtime Control Knobs B Assign
List").
The functions you specify here will be controlled when you
operate the REALTIME CONTROLS knobs [1]–[4] in B-
mode.
Since the REALTIME CONTROLS knob [1]–[4] function of
the B-mode assignments made for the programs assigned to
each timbre are not valid for the combination, new functions
must be set by these parameters.
Knob1–B (Knob1–B Assign)
Knob2–B (Knob2–B Assign)
Knob3–B (Knob3–B Assign)
Knob4–B (Knob4–B Assign)
2.2–1b: SW1/2 Assign
These settings assign the function of the [SW1] key and
[SW2] key (☞p.224 "SW1, SW2 Assign List").
Since the function assignments of the [SW1] key and [SW2]
key made for the programs assigned to each timbre are not
valid for the combination, new functions must be set by
these parameters.
SW1 (SW1 Assign)
SW1 Mode
SW2 (SW2 Assign)
SW2 Mode
( ☞ PROG 2.2–1b)
■ 2.2–1c: UTILITY
☞"Write Combination," "Solo Selected Timbre" (1.1–1c)
36
2.2–1b
2.2–1c
[Off...MIDI CC#95]
[Off...MIDI CC#95]
[Off...MIDI CC#95]
[Off...MIDI CC#95]
[Off...AfterT Lock]
[Toggle, Momentar y]
[Off...AfterT Lock]
[Toggle, Momentar y]
COMBI 3.1: Ed–Param1
3.1–1: MIDI
Here you can make MIDI settings for each timbre.
3.1–1a
3.1–1a: Status, MIDI Channel, Bank(EX2) MSB/LSB
Status
Specifies the status of MIDI and the internal tone generator
for each timbre.
INT: When you play this instrument, the internal tone gen-
erator will sound, and will also sound in respond to MIDI
messages received from an external MIDI device.
Off: The program will not sound. Nor will MIDI data be
transmitted.
EXT: Playing this instrument will not cause it to sound, but
it will transmit data via MIDI to control external MIDI
devices.
EX2: "Bank (EX2) MSB" and "Bank (EX2) LSB" (3.1–1a) will
be enabled. Instead of the bank numbers for A–G(d) that can
be selected on this instrument, the bank numbers you spec-
ify here will be transmitted via MIDI. In other respects this is
the same as EXT.
INT
EXT, EX2
MIDI Channel
Set the MIDI transmit/receive channel for each timbre 1–8.
Gch: The timbre will use the channel that has been selected
as the global MIDI channel "MIDI Channel" (GLOBAL 2.1–
1a).
When "Status" is INT, MIDI messages will be received on
the channel you specify here. If this setting is the same as the
global MIDI channel, the internal tone generator will sound
according to the internal settings. If this is set to EXT or EX2,
playing this instrument will transmit MIDI messages on the
MIDI channel specified here. (Messages will also be trans-
mitted simultaneously on the global MIDI channel.)
Bank(EX2) MSB
Bank(EX2) LSB
Specifies the bank number that will be transmitted when
"Status" is set to EX2. If "Status" is not set to EX2, this set-
ting has no effect.
■ 3.1–1b: UTILITY
☞"Write Combination," "Solo Selected Timbre" (1.1–1c)
3.1–1b
[INT, Off, EXT, EX2]
MIDI IN
Tone
generator
MIDI OUT
[01...16, Gch]
[000:000...127:127]
[000:000...127:127]
