KORG TR88
SERVICE MANUAL
TABLE OF CONTENTS
ASSEMBLY SKETCH (HOOKUP): 2
BLOCK DIAGRAM: 3
SCHEMATIC DIAGRAM: 4-14
TEST MODE:15
PARTS LIST: 16-18
Issued Jun.29, 2006
Ver1

Advertisement

   Related Manuals for Korg TR88

   Summary of Contents for Korg TR88

  • Page 1

    KORG TR88 SERVICE MANUAL TABLE OF CONTENTS ASSEMBLY SKETCH (HOOKUP): 2 BLOCK DIAGRAM: 3 SCHEMATIC DIAGRAM: 4-14 TEST MODE:15 PARTS LIST: 16-18 Issued Jun.29, 2006 Ver1...

  • Page 2

    1 6 2 3 4 5 7 8 9 2 0 1 2 1 1 1 0 1 4 1 3 1 5 1 6 1 7 1 8 N O . P A R T   C O D E P...

  • Page 12

    4 >...

  • Page 15

    TR61/TR76/TR88 TEST MODE How to start the test mode ENTER+5+POWER ON : FULL TEST(61/76Key) MENU+5+POWER ON : FULL TEST(88Key) ENTER+2+POWER ON : OMIT THE INERNAL TEST How to operate the test mode ENTER : PROCEED THE TEST VALUE▲ : ITEM UP VALUE▼...

  • Page 16

    KORG TR88 Parts List Part Name Part No. Note 200033272278 KLM-2278/79/80/81 LE TR (ASS'Y) 200033272304 KLM-2304/2305 JOYSTIC (ASS'Y) 200036072331 KLM-2331/32 TRITON LE88/TR88 (ASS'Y) 200036072387 KLM-2387 TRITON LE88/TR88 (ASS'Y) (1/4) 200056632676 KLM-2676 TR88 (ASS'Y) 500304050220 DTC114ESA TP KLM2278/79/80/81 500304050270 DTB113ZSTP KLM2278/79/80/81...

  • Page 17

    Part No. Part Name Note 500324021160 NE5532DR KLM-2676 500324003010 TC7WU04F TE12L KLM-2676 500324007011 BA09FP-E2 KLM-2676 500324007012 BA033LBSG2-TR KLM-2676 500324011004 M5216FP-600C KLM-2676 500324017014 RN5VD45AA-TR KLM-2676 500324021168 SN74LVC1G04DCKR KLM-2676 500324021190 SN74LVC1G19DCKR KLM-2676 500324021180 SN74LVC1G125DCKR KLM-2676 500324021200 SN74LVC1G332DCKR KLM-2676 500324021026 SN74AHCT541PWR KLM-2676 500324021270 SN74AHCT574PWR(TS) KLM-2676 500324021271...

  • Page 18

    Part No. Part Name Note 500475003181 HARNESS HNS-3181 ELCTRONIC 500475003182 HARNESS HNS-3182 ELCTRONIC 500475003183 HARNESS HNS-3183 ELCTRONIC 500475003184 HARNESS HNS-3184 ELCTRONIC 500475003185 HARNESS HNS-3185 ELCTRONIC 500475003186 HARNESS HNS-3186 ELCTRONIC 500475003187 HARNESS HNS-3187 ELCTRONIC 500475102941 HARNESS HNS-2941(L=400MM/20PIN) ELCTRONIC 500540026500 X-0100 JS WASHER KOC-F40979 MECHANICAL 500550019400 X-2110 KB FELT 5 KOC-F41031...
