Korg TRITON Classic Easy Start

Music workstation synthesizer
Hide thumbs
1
2
3
4
5
6
7

Advertisement

Quick Links

Download this manual
EasyStart
• Incredible sound: 32MB of waveform ROM,
expandable with EXB-PCM expansion boards, and
EXB-MOSS DSP synthesis board.
• World -class Effects: 102 algorithms, 5 inserts, 2
masters include sync-able effects, 3-Band EQ.
• Quick, powerful Sampling: 16 MB RAM
(expandable to 64 MB), 48kHZ sampling rate,
Slicing, Time Stretching, Cross-fade Looping.
Important Info about OS V2.5; Loading the preload data
Listening to the Demo Songs
Selecting and playing Programs and Combinations
Arpeggiator Mode
Sequence Mode; Tap Tempo
One Touch Record; Combis with Arps
Swing Quantize; Sampling Mode
More new features of O.S. V2.5
TRITON "Classic" Main Features
EasyStart CONTENTS
• Easy and creative Sequencing: 16 Tracks,
200,000 events, with Cue List and RPPR
functions, shortcuts like Song Templates, preset
rhythm patterns, independent track-looping.
• Dual polyphonic Arpeggiators, 237 User
locations, sync-able to MIDI clock
• TouchView graphic interface makes navigation a
breeze
NEW OS
2.5 INFO
INSIDE !
2
2
3
4
4
5
6
7

Advertisement

loading

Related Manuals for Korg TRITON Classic

Summary of Contents for Korg TRITON Classic

  • Page 1 NEW OS EasyStart 2.5 INFO INSIDE ! TRITON “Classic” Main Features • Incredible sound: 32MB of waveform ROM, • Easy and creative Sequencing: 16 Tracks, expandable with EXB-PCM expansion boards, and 200,000 events, with Cue List and RPPR EXB-MOSS DSP synthesis board. functions, shortcuts like Song Templates, preset •...
  • Page 2 TRITON EasyStart Important information: Triton version 2.5 Operating System upgrade! Throughout this guide you will find paragraphs marked NEW!, which highlight some of the new features of Triton OS V2.5’s operating system! Loading the preload data Make sure to backup any of your own internal songs/sounds to floppy disk before proceeding! Insert TNFD-00P into the disk drive press the [DISK] key.
  • Page 3 TRITON EasyStart Selecting and playing Programs and Combinations To select Programs, press the [PROG] key. To select Combinations, press the [COMBI] key. Then press a [BANK] key to select one of the sound banks, followed by using the DIAL, [INC]/[DEC] keys, or numeric keypad to select sounds from within a bank.

  • Page 4: Arpeggiator Mode

    TRITON EasyStart Arpeggiator mode TRITON has dual polyphonic arpeggiators, fully editable and syncable to MIDI clock. One program uses one arpeggio pattern - Combi or Sequence modes use up to two arpeggio patterns at once. Programs have an arpeggio pattern assigned to them even if the Arpeggiator [ON/OFF] key does not “wake up” in the ON position.
  • Page 5 TRITON EasyStart Press the PlyLoop 1-8 tab at the bottom of the screen Press the Track Play Loop checkbox for Track 2 Leave the Loop Start Measure at “001” Press the Loop End Measure and set it to the last measure you played on Track 2 (using INC, dial, or keypad) Press [LOCATE] to move to the song beginning, and then press the [START/STOP] key to play back the song and looped bass track...
  • Page 6 TRITON EasyStart Press [START/STOP] to begin recording Press [START/STOP] again to stop recording. What could be easier?! New! Alternate song method for copying Combis with Arps: Choose any Combi with the [ARP ON/OFF] switch on (lit). Create a new song Press the upper right corner drop-down menu and press “Copy from Combi”...
  • Page 7 Individual Output for Metronome Click when Sampling: Now there can be a tempo reference, not only a countoff, for sampling. File Compatibility: Sound and song files may be shared between ALL the Korg workstation instruments. Bulletproof Sequence memory: Even if you should use all available sequencer memory, the data you’ve already recorded is...
