VIDEO BOARD

The system features a Matrox MGA Millennium™ 64-bit, PCI local bus, Window random
access memory (WRAM) graphics accelerator, with 2 or 4 MB of video WRAM. The MGA
Millennium integrates true color, digital video and 3D into a single chip. MGA Millennium
provides up to 200 Hz flicker-free refresh. The 3D graphics engine renders your 3D
applications in photo-realistic colors and textures for you to manipulate in real-time.
In addition to the standard VGA connector, a video feature connector is supplied on the
MGA Millennium video board. The following subsections provide information about the
graphics features.

Video Support

System comes with 2 MB of dual ported WRAM on the video board, upgradeable to 4 MB
of WRAM. Network configurations come with 4 MB of WRAM, upgradeable to 8 MB.
The default video mode is 800 by 600 pixels with 256 colors. Change the default video
resolution using the Windows Control Panel (see Matrox Video Driver Installation in
Section 2.
To take full advantage of the computer's installed video board and extended graphics
modes listed below, use the video driver diskettes that ships with the system. The included
driver diskettes are listed earlier in this section.
When the video board contains 2 MB of video WRAM, the following resolutions are
available:
n
640 by 480 - 256, 65K, and 16.7 colors
n
1024 by 768 - 256 and 65K colors
n
1152 by 882 - 256 and 65K colors
n
1280 by 1024, 256 colors
n
1600 by 1200, 256 colors.
When the video board contains 4 MB of video WRAM, the following resolutions are
available:
n
640 by 480 - 256, 65K, and 16.7 colors
n
1024 by 768 - 256, 65K, and 16.7 colors
n
1152 by 882 - 256, 65K, and 16.7 colors
n
1280 by 1024 - 256, 65K, and 16.7 colors
n
1600 by 1200 - 256 and 65K colors.
Technical Information 1-13
