5-14 System Unit Repair

Illustrated Parts Breakdown

This subsection contains the illustrated parts breakdown (IPB) and NEC part numbers for
the PowerMate Ve computer. Table 5-2 lists the field-replaceable parts for the computer.
Figure 5-16 is the illustrated parts breakdown.
Table 5-2 PowerMate Ve Field-Replaceable Parts List*
Item Description
1 Second Serial Interface & Cable Assembly
2 Fan Assembly
3 3 1/2-Inch 1.2 GB IDE Hard Drive
4 3 1/2-Inch Hard Drive IDE Signal Cable
(3 connector)
5 3 1/2-Inch Diskette Drive Signal Cable
(3 connector)
6 Card Edge Guide
7 3 1/2-Inch 1.44 MB Diskette Drive
8 CD-ROM Reader IDE Signal Cable
(2 connector)
9 3 1/2-Inch Drive Bracket
10 CMOS 3 Volt Lithium Coin Battery
11 Audio Cable (for CD-ROM)
12 PCI/ISA Backboard
13 System Unit Cover
14 256 KB L2 Synchronous Pipeline Burst
Cache 15 ns
15A 4 MB EDO SIMM
15B 8 MB EDO SIMM
16 Heatsink w/Clip
____________
* This data was prepared August 1996. For an up-to-date listing of spare parts, please call FastFacts (800) 366-0476
and order document number 42181528.
NOTE: Dealers in the U.S., should call 1(800)
632-4525 to order NEC spare parts. All other
user's in the U.S. must call 1(800) 233-6321 for
parts. To order options in the U.S., call the NEC
sales office at 1(800) NEC-INFO.
Part Number
158-050454-004
158-050865-006
158-050395-366
158-050562-008
158-050503-002
158-050883-005
158-050966-000
158-050562-004
158-030807-000
158-060367-000
158-050824-000
158-026204-000A
158-050883-002
158-082737-015
158-082629-060
158-082630-060
158-060324-001
