5-14 System Unit Repair

Illustrated Parts Breakdown

This subsection contains the illustrated parts breakdown (IPB) and NEC part numbers for
the PowerMate Ve computer. Table Section 5-2 lists the field-replaceable parts for the
computer. Figure Section 5-16 is the illustrated parts breakdown.
Table Section 5-2 PowerMate Ve Field-Replaceable Parts List*
Item Description
1 Mouse, PS/2
2A 3 1/2-Inch 635 MB Hard Drive
2B 3 1/2-Inch 1.2 GB Hard Drive
3 3 1/2-Inch 1.44 MB Diskette Drive
4 3 1/2-Inch Drive Bracket
5 3 1/2-Inch Diskette Drive Signal Cable
(3 connector)
6 3 1/2-Inch Hard Drive IDE Signal Cable
(3 connector)
7 CD-ROM Reader IDE Signal Cable
(2 connector)
8 Ethernet Network Interface Card
(network-ready systems only)
9 PCI/ISA Backboard
10 System Unit Cover
11A 4 MB, 1x32 EDO SIMMs (2)
11B 8 MB, 2x32 EDO SIMMs (2)
12 5 Watt External Speakers with Cables
13 Power Supply
14 CPU Heatsink (with clip)
15A Pentium 75 MHz Processor
____________
* This data was prepared May 1996. For an up-to-date listing of spare parts, please call FastFacts (800) 366-0476
and order document number 42181406.
NOTE: Dealers in the U.S., should call 1(800)
632-4525 to order NEC spare parts. All other
user's in the U.S. must call 1(800) 233-6321 for
parts. To order options in the U.S., call the NEC
sales office at 1(800) NEC-INFO.
Part Number
158-050789-000
158-050395-365
158-050395-366
158-050966-000
158-030807-000
158-050503-002
158-050562-008
158-050562-004
158-050796-000
158-026204-000A
158-050883-002
158-082629-060
158-082630-060
158-050990-000
158-050730-000
158-060324-001
158-082502-006
