Diagnostics and troubleshooting
96
Diagnostic information pertaining to the configuration: diagnostic number 400 to 599
Diagnostic behavior
(configurable)
Quality
Alarm BAD
UNCERTA
Warning
IN
Logbook entry only
GOOD
Off
Diagnostic information pertaining to the process: diagnostic number 800 to 999
Diagnostic behavior
(configurable)
Quality
Alarm BAD
UNCERTA
Warning
IN
Logbook entry only
GOOD
Off
12.6 Overview of diagnostic information
• The amount of diagnostic information and the number of measured variables
affected increase if the measuring device has one or more application packages.
• All of the measured variables affected in the entire Promass instrument family are
always listed under "Measured variables affected". The measured variables available
for the device in question depend on the device version. When assigning the
measured variables to the device functions, for example to the individual outputs, all
of the measured variables available for the device version in question are available
for selection.
In the case of some items of diagnostic information, the diagnostic behavior can be
changed. Adapting the diagnostic information →  93
Measured value status (fixed assignment)
Quality Coding
Substatus (hex)
Process
0x28
related
Process
0x78
related
ok 0x80
Measured value status (fixed assignment)
Quality Coding
Substatus (hex)
Process
0x28
related
Process
0x78
related
ok 0x80
Proline Promass A 100 PROFINET
Device diagnosis
Category
(fixed assignment)
(NE107)
F Invalid process
(Failure) condition
S
Invalid process
(Out of
condition
specification)
– –
Device diagnosis
Category
(fixed assignment)
(NE107)
F Invalid process
(Failure) condition
S
Invalid process
(Out of
condition
specification)
– –
