Proline Promass A 100 PROFINET
Endress+Hauser
9.3 Cyclic data transmission
9.3.1 Overview of the modules
The following tables shows which modules are available to the measuring device for cyclic
data exchange. Cyclic data exchange is performed with an automation system.
Measuring device
Modules
Analog Input module →  51
Digital Input module →  52
Diagnose Input module →  53
Analog Output module →  56
Digital Output module →  57
Totalizer 1 to 3 →  54
Heartbeat Verification module →  58
9.3.2 Description of the modules
The data structure is described from the perspective of the automation system:
• Input data: Are sent from the measuring device to the automation system.
• Output data: Are sent from the automation system to the measuring device.
Analog Input module
Transmit input variables from the measuring device to the automation system.
Analog Input modules cyclically transmit the selected input variables, along with the
status, from the measuring device to the automation system. The input variable is depicted
in the first four bytes in the form of a floating point number as per the IEEE 754 standard.
The fifth byte contains status information pertaining to the input variable.
Selection: input variable
Slot Input variables
• Mass flow
• Volume flow
• Corrected volume flow
• Target mass flow
• Carrier mass flow
• Density
• Reference density
• Concentration
• Temperature
1 to 14
• Carrier tube temperature
• Electronic temperature
• Oscillation frequency
• Oscillation amplitude
• Frequency fluctuation
• Oscillation damping
• Tube damping fluctuation
• Signal asymmetry
• Exciter current
1) Only available with the Concentration application package
2) Only available with the Heartbeat Verification application package
Direction
Data flow
Slot
1 to 14 →
1 to 14 →
1 to 14 →
18, 19, 20 ←
21, 22 ←
←
15 to 17
→
←
23
→
1)
2)
System integration
Control system
PROFINET
51
