Proline Promass A 100 PROFINET
Endress+Hauser
The diagnostic information is grouped as follows:
• Diagnostic information pertaining to the sensor: diagnostic number 000 to 199
→  95
• Diagnostic information pertaining to the electronics: diagnostic number 200 to 399
→  95
• Diagnostic information pertaining to the configuration: diagnostic number 400 to 599
→  96
• Diagnostic information pertaining to the process: diagnostic number 800 to 999
→  96
Depending on the group in which the diagnostic information is located, the following
measured value status and device status are firmly assigned to the particular diagnostic
behavior:
Diagnostic information pertaining to the sensor: diagnostic number 000 to 199
Diagnostic behavior
(configurable)
Quality
Alarm BAD
Warning GOOD
Logbook entry only
GOOD
Off
Diagnostic information pertaining to the electronics: diagnostic number 200 to 399
Diagnostic number 200 to 301, 303 to 399
Diagnostic behavior
(configurable)
Quality
Alarm
BAD
Warning
Logbook entry only
GOOD
Off
Diagnostic information 302
Diagnostic behavior
(configurable)
Quality
Alarm BAD
Warning GOOD
Diagnostic information 302 (device verification active) is output during internal or
external Heartbeat verification.
• Signal status: Function check
• Choice of diagnostic behavior: alarm or warning (factory setting)
When the Heartbeat Verification is started, data logging is interrupted, the last valid
measured value is output and the totalizer counter is stopped.
Measured value status (fixed assignment)
Quality Coding
Substatus (hex)
Maintenance
0x24
alarm
Maintenance
0xA8
demanded
ok 0x80
Measured value status (fixed assignment)
Quality Coding
Substatus (hex)
Maintenance
0x24
alarm
ok 0x80 to 0x8E
Measured value status (fixed assignment)
Quality Coding
Substatus (hex)
Function check,
0x24
local override
Function check 0xBC to 0xBF
Diagnostics and troubleshooting
Device diagnosis
Category
(fixed assignment)
(NE107)
F Maintenance
(Failure) alarm
M Maintenance
(Maintenance) demanded
– –
Device diagnostics
Category
(fixed assignment)
(NE107)
F Maintenance
(Failure) alarm
– –
Device diagnostics
Category
(fixed assignment)
(NE107)
C Function check
– –
