Proline Promass A 100 PROFINET
Design, dimensions
Weight
Materials
Endress+Hauser
16.10 Mechanical construction
For the dimensions and installation lengths of the device, see the "Technical
Information" document, "Mechanical construction" section
All values (weight exclusive of packaging material) refer to devices with EN/DIN
PN 40 flanges. Weight specifications including transmitter: order code for "Housing",
option A "Compact, aluminum coated".
Weight in SI units
DN
[mm]
1
2
4
Weight in US units
DN
[in]
1/24
1/12
1/8
Transmitter housing
• Order code for "Housing", option A "Compact, aluminum coated":
Aluminum, AlSi10Mg, coated
• Order code for "Housing", option B "Compact, hygienic, stainless":
Hygienic version, stainless steel 1.4301 (304)
• Order code for "Housing", option C "Ultra-compact, hygienic, stainless":
Hygienic version, stainless steel 1.4301 (304)
• Window material for optional local display (→  148):
• For order code for "Housing", option A: glass
• For order code for "Housing", option B and C: plastic
Technical data
Weight [kg]
8
9
13
Weight [lbs]
18
20
29
145
