Endress+Hauser Proline Promass A 100 PROFINET Operating Instructions Manual page 31

Proline Promass A 100 PROFINET
Endress+Hauser
7.3.1 Connecting the transmitter
The connection of the transmitter depends on the following order codes:
• Housing version: compact or ultra-compact
• Connection version: device plug or terminals
A
1
 8 Housing versions and connection versions
A Housing version: compact, coated, aluminum
B Housing version: compact, hygienic, stainless
1 Cable entry or device plug for signal transmission
2 Cable entry or device plug for supply voltage
C Housing version: ultra-compact, hygienic, stainless
3 Device plug for signal transmission
4 Device plug for supply voltage
3 mm
2
1
mm (in)
 9 Device versions with connection examples
1 Cable
2 Device plug for signal transmission
3 Device plug for supply voltage
B
2 1 2
8 mm
2
1
1 2
10 (0.4)
Electrical connection
C
3 4
8 mm
2
3
3
A0016924
A0017844
31
