System integration
54
Coding (hex)
0x02
0x04
0x08
Totalizer module
The Totalizer module consists of the Totalizer Value, Totalizer Control and Totalizer Mode
submodules.
Totalizer Value submodule
Transmit transmitter value from the device to the automation system.
Totalizer modules cyclically transmit a selected totalizer value, along with the status, from
the measuring device to the automation system via the Totalizer Value submodule. The
totalizer value is depicted in the first four bytes in the form of a floating point number as
per the IEEE 754 standard. The fifth byte contains status information pertaining to the
totalizer value.
Selection: input variable
Slot Sub-slot
15...17 1
1) Only available with the Concentration application package
Data structure of input data (Totalizer Value submodule)
Byte 1 Byte 2
Measured value: floating point number (IEEE 754)
1) Status coding →  59
Totalizer Control module
Transmit totalizer value from the measuring device to the automation system.
Selection: input variable
Data structure
Totalizer Control input data
Byte 1 Byte 2
Measured value: floating point number (IEEE 754)
1) Status coding
Status
Function check (C):
The device is in service mode (e.g. during a simulation).
Maintenance required (M):
Maintenance is required. The measured value is still valid.
Out of specification (S):
The device is being operated outside its technical specification limits (e.g.
process temperature range).
Input variable
• Mass flow
• Volume flow
• Corrected volume flow
1)
• Target mass flow
1)
• Carrier mass flow
Byte 3 Byte 4
Byte 3 Byte 4
Proline Promass A 100 PROFINET
Byte 5
1)
Status
Byte 5
1)
Status
