Installation
24
Verification and adjustment cannot be carried out if the following process conditions are
present:
• Gas pockets
Ensure that the system has been sufficiently flushed with the medium. Repeat flushing
can help to eliminate gas pockets
• Thermal circulation
In the event of temperature differences (e.g. between the measuring tube inlet and
outlet section), induced flow can occur even if the valves are closed due to thermal
circulation in the device
• Leaks at the valves
If the valves are not leak-tight, flow is not sufficiently prevented when determining the
zero point
If these conditions cannot be avoided, it is advisable to keep the factory setting for the zero
point.
Wall mounting
WARNING
L
Incorrect sensor mounting
Risk of injury if measuring tube breaks
‣
The sensor should never be installed in a pipe in a way that it is freely suspended
‣
Using the base plate, mount the sensor directly on the floor, wall or ceiling.
‣
Support the sensor on a securely mounted support base (e.g. angle bracket).
The following mounting versions are recommended for the installation.
Vertical
• Mounted directly on a wall using the base plate, or
• Device supported on an angle bracket mounted on the wall
Horizontal
Device standing on a solid support base
Post retainer
The post retainer mounting kit is used to secure the device to a pipe or post (order code for
"Accessories", option PR).
