Proline Promass A 100 PROFINET
Endress+Hauser
4.2.2 Sensor nameplate
14
13
 3 Example of a sensor nameplate
1 Name of the sensor
2 Manufacturer address/certificate holder
3 Order code
4 Serial number (Ser. no.)
5 Extended order code (Ext. ord. cd.)
6 Nominal diameter of the sensor; flange nominal diameter/nominal pressure; sensor test pressure; medium
temperature range; material of measuring tube and manifold; sensor-specific information: e.g. pressure range
of sensor housing, wide-range density specification (special density calibration)
7 Approval information for explosion protection, Pressure Equipment Directive and degree of protection
8 Flow direction
9 Date of manufacture: year-month
10 2-D matrix code
11 Document number of safety-related supplementary documentation
12 CE mark, RCM-Tick mark
13 Surface roughness
14 Allowable ambient temperature (T
Order code
The measuring device is reordered using the order code.
Extended order code
• The device type (product root) and basic specifications (mandatory features) are
always listed.
• Of the optional specifications (optional features), only the safety and approval-
related specifications are listed (e.g. LA). If other optional specifications are also
ordered, these are indicated collectively using the # placeholder symbol (e.g. #LA#).
• If the ordered optional specifications do not include any safety and approval-related
specifications, they are indicated by the + placeholder symbol (e.g. XXXXXX-ABCDE
+).
Incoming acceptance and product identification
1
Order code:
Ser. no.:
Ext. ord. cd.:
i
i
12 11
)
a
2
3
4
5
6
7
8
Date:
9
10
A0029199
