Technical data
Low flow cut off
Galvanic isolation
Protocol-specific data
132
Interface/protocol
• Via digital communication:
PROFINET
• Via service interface
CDI-RJ45 service interface
Plain text display With information on cause and remedial measures
Web browser
Plain text display With information on cause and remedial measures
Light emitting diodes (LED)
Status information
The switch points for low flow cut off are user-selectable.
The following connections are galvanically isolated from each other:
• Outputs
• Power supply
protocol-specific data
Protocol
Conformity class
Communication type
Device profile
Manufacturer ID
Device type ID
Device description files (GSD,
DTM)
Baud rates
Periods
Polarity
Supported connections
Status indicated by various light emitting diodes
The following information is displayed depending on the device version:
• Supply voltage active
• Data transmission active
• Device alarm/error has occurred
• PROFINET network available
• PROFINET connection established
• PROFINET blinking feature

Diagnostic information via light emitting diodes
"Application layer protocol for decentral device periphery and distributed
automation", version 2.3
B
100 Mbps
Application interface identifier 0xF600
Generic device
0x11
0x844A
Information and files available at:
• https://www.endress.com/download
On the device product page: PRODUCTS → Product Finder → Links
• https://www.profibus.com
Automatic 100 Mbit/s with full-duplex detection
From 8 ms
Auto-polarity for automatic correction of crossed TxD and RxD pairs
• 1 x AR (Application Relation)
• 1 x Input CR (Communication Relation)
• 1 x Output CR (Communication Relation)
• 1 x Alarm CR (Communication Relation)
