Diagnostics and troubleshooting
For local display
Error
Local display is dark, but signal output is within
the valid range
Local display dark and no output signals
Local display dark and no output signals
Local display dark and no output signals
Local display dark and no output signals
Local display dark and no output signals
Local display cannot be read, but signal output is
within the valid range
Local display is dark, but signal output is within
the valid range
Backlighting of local display is red
Message on local display:
"Communication Error"
"Check Electronics"
For output signals
Error
Green power LED on the main electronics
module of the transmitter is dark
Device measures incorrectly.
For access
Fault
Write access to parameters is not possible.
Connection via PROFINET is not possible.
Connection via PROFINET is not possible.
Unable to connect to the web server.
88
12 Diagnostics and troubleshooting
12.1 General troubleshooting
Possible causes
The cable of the display module is not plugged in
correctly.
Supply voltage does not match the voltage
specified on the nameplate.
Supply voltage has incorrect polarity.
No contact between connecting cables and
terminals.
• Terminals are not plugged into the I/O
electronics module correctly.
•
• I/O electronics module is defective.
•
Display is set too bright or too dark.
Display module is defective.
Diagnostic event with "Alarm" diagnostic
behavior has occurred.
Communication between the display module and
the electronics is interrupted.
Possible causes
Supply voltage does not match the voltage
specified on the nameplate.
Configuration error or device is operated outside
the application.
Possible causes
Hardware write protection is enabled.
PROFINET bus cable is incorrectly connected.
Device plug is incorrectly connected.
Web server is disabled.
Proline Promass A 100 PROFINET
Remedial action
Insert the plug correctly into the main
electronics module and display module.
Apply the correct supply voltage →  31.
Reverse polarity of supply voltage.
Ensure electrical contact between the cable and
the terminal.
Check terminals.
Order spare part →  124.
• Set the display brighter by simultaneously
pressing  + .
• Set the display darker by simultaneously
pressing  + .
Order spare part →  124.
Take remedial measures →  96
• Check the cable and the connector between
the main electronics module and display
module.
• Order spare part →  124.
Remedial action
Apply the correct supply voltage →  31.
1. Check and correct parameter configuration.
2. Observe limit values specified in the
"Technical Data".
Remedial action
Set the write protection switch on the main
electronics module to the OFF position →  80.
Check the terminal assignment →  29.
Check the pin assignment of the device plugs .
Using the "FieldCare" or "DeviceCare" operating
tool, check whether the web server of the device
is enabled, and enable it if necessary →  45.
