Operation options
Menu/parameter
Language Task- Role "Operator", "Maintenance"
oriented Tasks during operation:
• Configuration of the operational
Operation
• Reading measured values
Setup "Maintenance" role
Commissioning:
Configuration of the measurement
Diagnostics "Maintenance" role
Troubleshooting:
• Diagnostics and elimination of process
• Measured value simulation
Expert Function- Tasks that require detailed knowledge of
oriented the function of the device:
• Commissioning measurements under
• Optimal adaptation of the
• Detailed configuration of the
• Error diagnostics in difficult cases
38
8.2.2 Operating philosophy
The individual parts of the operating menu are assigned to certain user roles (e.g.
operator, maintenance etc.). Each user role contains typical tasks within the device life
cycle.
User role and tasks
display
and device errors
difficult conditions
measurement to difficult conditions
communication interface
Content/meaning
• Defining the operating language
• Defining the Web server operating language
• Resetting and controlling totalizers
• Configuration of the operational display (e.g. display format, display
contrast)
• Resetting and controlling totalizers
Submenus for fast commissioning:
• Configuring the system units
• Definition of the medium
• Configuration of the operational display
• Configuring the low flow cut off
• Configuring partial and empty pipe detection
Advanced setup
• For more customized configuration of the measurement (adaptation to
special measuring conditions)
• Configuration of totalizers
• Administration (define access code, reset measuring device)
Contains all parameters for error detection and analyzing process and device
errors:
• Diagnostic list
Contains up to 5 currently pending diagnostic messages.
• Event logbook
Contains event messages that have occurred.
• Device information
Contains information for identifying the device
• Measured values
Contains all current measured values.
• Heartbeat Technology
Verification of device functionality on request and documentation of
verification results
• Simulation
Used to simulate measured values or output values.
Contains all of the device parameters and allows direct access to these by
means of an access code. The structure of this menu is based on the function
blocks of the device:
• System
Contains all higher-level device parameters that do not affect
measurement or measured value communication
• Sensor
Configuration of the measurement.
• Communication
Configuration of the digital communication interface and the Web server
• Application
Configuration of the functions that go beyond the actual measurement
(e.g. totalizer)
• Diagnostics
Error detection and analysis of process and device errors and for device
simulation and Heartbeat Technology.
