Proline Promass A 100 PROFINET
Mounting requirements
Ambient temperature
range
Storage temperature
Climate class
Degree of protection
Shock and vibration
resistance
Endress+Hauser
Example of maximum measurement error
E [%]
2.5
2.0
1.5
1.0
0.5
0
0 10 20
E Maximum measurement error in % o.r. (example)
Q Flow rate in % of maximum full scale value
16.7 Mounting
→  19
16.8 Environment
→  21→  21
Temperature tables
Observe the interdependencies between the permitted ambient and fluid
temperatures when operating the device in hazardous areas.
For detailed information on the temperature tables, see the separate document
entitled "Safety Instructions" (XA) for the device.
–40 to +80 °C (–40 to +176 °F), preferably at +20 °C (+68 °F) (standard version)
–50 to +80 °C (–58 to +176 °F) (Order code for "Test, certificate", option JM)
DIN EN 60068-2-38 (test Z/AD)
Transmitter and sensor
• Standard: IP66/67, Type 4X enclosure, suitable for pollution degree 4
• With the order code for "Sensor options", option CM: IP69 can also be ordered
• When the housing is open: IP20, Type 1 enclosure, suitable for pollution degree 2
• Display module: IP20, Type 1 enclosure, suitable for pollution degree 2
Vibration sinusoidal, in accordance with IEC 60068-2-6
• 2 to 8.4 Hz, 3.5 mm peak
• 8.4 to 2 000 Hz, 1 g peak
Vibration broad-band random, according to IEC 60068-2-64
• 10 to 200 Hz, 0.003 g 2
• 200 to 2 000 Hz, 0.001 g
• Total: 1.54 g rms
30 40 50 60
/Hz
2 /Hz
Technical data
100 Q [%]
70 80 90
A0024173
