Proline Promass A 100 PROFINET
Endress+Hauser
Selection: output variable
Transmit the control value from the automation system to the measuring device.
Slot Sub-slot
70 to 71 1
Data structure
Totalizer Control output data
Totalizer Control submodule
Control the totalizer via the automation system.
Selection: control totalizer
Slot Sub-slot
15...17
2
Data structure of output data (Totalizer Control submodule)
Byte 1
Control variable
Totalizer Mode submodule
Configure the totalizer via the automation system.
Selection: totalizer configuration
Slot Sub-slot
15...17
3
Data structure of output data (Totalizer Mode submodule)
Byte 1
Configuration variable
Value Input variable
1 Reset to "0"
2 Preset value
3 Stop
4 Totalize
Byte 1
Control variable
Value Control totalizer
0 Totalize
1 Reset + hold
2 Preset + hold
3 Reset + totalize
4 Preset + totalize
5 Hold
Value Control totalizer
0 Balancing
1 Balance the positive flow
2 Balance the negative flow
System integration
