System integration
58
discrete input value is depicted in the first byte. The second byte contains status
information pertaining to the input value.
Only available with the Heartbeat Verification application package.
Assigned device functions
Slot Device function
Verification status
(input data)
23
Verification result
(input data)
Start the verification
(output data)
Data structure
Output data of Heartbeat Verification module
Byte 1
Discrete Output
Input data of Heartbeat Verification module
Byte 1 Byte 2
Discrete Input Status
1) Status coding →  59
Concentration module
Only available with the Concentration Measurement application package.
Assigned device functions
Slot Input variables
28 Selection of the liquid type
Data structure
Concentration output data
Byte 1
Control variable
Bit Verification status
0 Verification has not been performed
1 The device has failed the verification
2 Currently performing verification
3 Verification finished
Bit Verification result
4 The device has failed the verification
5 Verification performed successfully
6 Verification has not been performed
7 –
Verification control
A status change from 0 to 1 starts the verification
