Endress+Hauser Proline Promass A 100 PROFINET Operating Instructions Manual page 119

Proline Promass A 100 PROFINET
Endress+Hauser
In addition to the operating time when the event occurred, each event is also assigned a
symbol that indicates whether the event has occurred or is finished:
• Diagnostics event
• : Occurrence of the event
• : End of the event
• Information event
: Occurrence of the event
To call up the measures to rectify a diagnostic event:
• Via web browser →  92
• Via "FieldCare" operating tool →  93
• Via "DeviceCare" operating tool →  93
For filtering the displayed event messages →  119
12.9.2 Filtering the event logbook
Using the Filter options parameter you can define which category of event message is
displayed in the Events list submenu.
Navigation path
Diagnostics → Event logbook → Filter options
Filter categories
• All
• Failure (F)
• Function check (C)
• Out of specification (S)
• Maintenance required (M)
• Information (I)
12.9.3 Overview of information events
Unlike a diagnostic event, an information event is displayed in the event logbook only and
not in the diagnostic list.
Info number
I1000 --------(Device ok)
I1089 Power on
I1090 Configuration reset
I1091 Configuration changed
I1111 Density adjust failure
I1137 Electronic changed
I1151 History reset
I1155 Reset electronic temperature
I1157 Memory error event list
I1185 Display backup done
I1186 Restore via display done
I1187 Settings downloaded with display
I1188 Display data cleared
I1189 Backup compared
I1209 Density adjustment ok
I1221 Zero point adjust failure
I1222 Zero point adjustment ok
Diagnostics and troubleshooting
Info name
119
