Proline Promass A 100 PROFINET
Endress+Hauser
6.3 Post-installation check
Is the device undamaged (visual inspection)?
Does the measuring instrument correspond to the measuring point specifications?
For example:
• Process temperature →  142
• Pressure (refer to the "Pressure-temperature ratings" section of the "Technical Information"
document).
• Ambient temperature →  141
• Measuring range
Has the correct orientation for the sensor been selected →  20?
• According to sensor type
• According to medium temperature
• According to medium properties (outgassing, with entrained solids)
Does the arrow on the sensor match the direction of flow of the medium? →  20?
Is the tag name and labeling correct (visual inspection)?
Is the device sufficiently protected from precipitation and direct sunlight?
Are the securing screw and securing clamp tightened securely?
Installation







27
