Operation options
42
Measuring device: Via CDI-RJ45 service interface
Device
Measuring device
Web server
8.4.3 Connecting the device
Via service interface (CDI-RJ45)
Preparing the measuring device
Configuring the Internet protocol of the computer
The IP address can be assigned to the measuring device in a variety of ways:
• Dynamic Configuration Protocol (DCP), factory setting:
The IP address is automatically assigned to the measuring device by the automation
system (e.g. Siemens S7).
• Hardware addressing:
The IP address is set via DIP switches .
• Software addressing:
The IP address is entered via the IP address parameter (→  65) .
• DIP switch for "Default IP address":
To establish the network connection via the service interface (CDI-RJ45): the fixed IP
address 192.168.1.212 is used .
The device works with the Dynamic Configuration Protocol (DCP) ex-works, i.e. the IP
address of the measuring device is automatically assigned by the automation system (e.g.
Siemens S7).
To establish a network connection via the service interface (CDI-RJ45): set the "Default IP
address" DIP switch to ON. The measuring device then has the fixed IP address:
192.168.1.212. The fixed IP address 192.168.1.212 can now be used to establish the
connection to the network.
1. Via DIP switch 2, activate the default IP address 192.168.1.212: .
2. Switch on the measuring device.
3. Connect the computer to the RJ45 plug via the standard Ethernet cable →  149.
4. If a 2nd network card is not used, close all the applications on the notebook.
 Applications requiring Internet or a network, such as e-mail, SAP applications,
Internet or Windows Explorer.
5. Close any open Internet browsers.
6. Configure the properties of the Internet protocol (TCP/IP) as defined in the table:
IP address 192.168.1.XXX; for XXX all numerical sequences except: 0, 212 and 255 → e.g.
192.168.1.213
Subnet mask 255.255.255.0
Default gateway 192.168.1.212 or leave cells empty
Starting the web browser
1. Start the web browser on the computer.
CDI-RJ45 service interface
The measuring device has an RJ45 interface.
Web server must be enabled; factory setting: ON

For information on enabling the Web server →  45
