Proline Promass A 100 PROFINET
Parameter
Assign simulation process variable
Process variable value
Simulation device alarm
Diagnostic event category
Diagnostic event simulation
* Visibility depends on order options or device settings
Endress+Hauser
Navigation
"Diagnostics" menu → Simulation
‣
Simulation
Assign simulation process variable
Process variable value
Simulation device alarm
Diagnostic event simulation
Parameter overview with brief description
Prerequisite
–
A process variable is selected in the
Assign simulation process variable
parameter (→  79).
–
–
–
10.9 Protecting settings from unauthorized access
The following options exist for protecting the configuration of the measuring device from
unintentional modification after commissioning:
• Write protection via access code for Web browser →  79
• Write protection via write protection switch →  80
• Write protection via startup parameterization →  62
10.9.1 Write protection via access code
With the customer-specific access code, access to the measuring instrument via the Web
browser is protected, as are the parameters for the measuring instrument configuration.
Description
Select a process variable for the
simulation process that is activated.
Enter the simulation value for the
selected process variable.
Switch the device alarm on and off.
Select a diagnostic event category.
Select a diagnostic event to simulate
this event.
Commissioning
→  79
→  79
→  79
→  79
Selection / User entry
• Off
• Mass flow
• Volume flow
• Corrected volume flow
• Density
• Reference density
• Temperature
*
• Concentration
*
• Target mass flow
*
• Carrier mass flow
Depends on the process
variable selected
• Off
• On
• Sensor
• Electronics
• Configuration
• Process
• Off
• Diagnostic event picklist
(depends on the category
selected)
