Commissioning
Parameter
Assign process variable
Low value partial filled pipe
detection
High value partial filled pipe
detection
Response time part. filled pipe
detect.
70
10.6.6 Configuring partially filled pipe detection
The Partially filled pipe detection submenu contains parameters that have to be set for
configuring empty pipe detection.
Navigation
"Setup" menu → Partially filled pipe detection
‣
Partially filled pipe detection
Assign process variable
Low value partial filled pipe detection
High value partial filled pipe detection
Response time part. filled pipe detect.
Parameter overview with brief description
Prerequisite
–
A process variable is selected
in the Assign process variable
parameter (→  70).
A process variable is selected
in the Assign process variable
parameter (→  70).
A process variable is selected
in the Assign process variable
parameter (→  70).
Description
Select process variable for
partially filled pipe detection.
Enter lower limit value for
deactivating partialy filled pipe
detection.
Enter upper limit value for
deactivating partialy filled pipe
detection.
Use this function to enter the
minimum time (hold time) the
signal must be present before
diagnostic message S962 "Pipe
only partly filled" is triggered in
the event of a partially filled or
empty measuring pipe.
Proline Promass A 100 PROFINET
→  70
→  70
→  70
→  70
Selection / User Factory setting
entry
• Off Density
• Density
• Reference density
Signed floating-point Depends on country:
number • 200 kg/m
• 12.5 lb/ft
Signed floating-point Depends on country:
number • 6 000 kg/m
• 374.6 lb/ft
0 to 100 s –
