Endress+Hauser Proline Promass A 100 PROFINET Operating Instructions Manual page 150

Technical data
CE mark
UKCA marking
Ex-approval
Hygienic compatibility
Certification PROFINET
150
16.12 Certificates and approvals
Current certificates and approvals for the product are available at
relevant product page:
1. Select the product using the filters and search field.
2. Open the product page.
3. Select Downloads.
The device meets the legal requirements of the applicable EU Directives. These are listed in
the corresponding EU Declaration of Conformity along with the standards applied.
Endress+Hauser confirms successful testing of the device by affixing to it the CE mark.
The device meets the legal requirements of the applicable UK regulations (Statutory
Instruments). These are listed in the UKCA Declaration of Conformity along with the
designated standards. By selecting the order option for UKCA marking, Endress+Hauser
confirms a successful evaluation and testing of the device by affixing the UKCA mark.
Contact address Endress+Hauser UK:
Endress+Hauser Ltd.
Floats Road
Manchester M23 9NF
United Kingdom
www.uk.endress.com
The devices are certified for use in hazardous areas and the relevant safety instructions are
provided in the separate "Safety Instructions" (XA) document. Reference is made to this
document on the nameplate.
3-A approval
• Only measuring instruments with the order code for "Additional approval", option LP "3A"
have 3-A approval.
• The 3-A approval refers to the measuring instrument.
• When installing the measuring instrument, ensure that no liquid can accumulate on the
outside of the measuring instrument.
A remote display module must be installed in accordance with the 3-A Standard.
• Accessories (e.g. heating jacket, weather protection cover, wall holder unit) must be
installed in accordance with the 3-A Standard.
Each accessory can be cleaned. Disassembly may be necessary under certain
circumstances.
Observe the special installation instructions
PROFINET interface
The measuring device is certified and registered by the PNO (PROFIBUS
Nutzerorganisation e.V. / PROFIBUS User Organization). The measuring system meets all
the requirements of the following specifications:
• Certified according to:
• Test specification for PROFINET devices
• PROFINET Security Level 1– Netload Class 2 0 Mbps
• The device can also be operated with certified devices of other manufacturers
(interoperability)
• The device supports PROFINET S2 system redundancy.
Proline Promass A 100 PROFINET
