Proline Promass A 100 PROFINET
Power consumption
Current consumption
Device fuse
Power supply failure
Electrical connection
Potential equalization
Terminals
Cable entries
Cable specification
Reference operating
conditions
Maximum measurement
error
Endress+Hauser
Transmitter
Order code for "Output"
Option R: PROFINET
Transmitter
Order code for "Output"
Option R: PROFINET
Fine-wire fuse (slow-blow) T2A
• Totalizers stop at the last value measured.
• Depending on the device version, the configuration is retained in the device memory or
in the pluggable data memory (HistoROM DAT).
• Error messages (incl. total operated hours) are stored.
→  30
→  32
Transmitter
Spring terminals for wire cross-sections0.5 to 2.5 mm
• Cable gland: M20 × 1.5 with cable Ø 6 to 12 mm (0.24 to 0.47 in)
• Thread for cable entry:
• M20
• G ½"
• NPT ½"
→  28
16.6 Performance characteristics
• Error limits based on ISO 11631
• Water
• +15 to +45 °C (+59 to +113 °F)
• 2 to 6 bar (29 to 87 psi)
• Data as indicated in the calibration protocol
• Accuracy based on accredited calibration rigs according to ISO 17025
To obtain measured errors, use the Applicator sizing tool →  127
o.r. = of reading; 1 g/cm³ = 1 kg/l; T = medium temperature
Maximum
Power consumption
Maximum
Current consumption switch-on current
145 mA 18 A (< 0.125 ms)
2
(20 to 14 AWG)
Technical data
3.5 W
Maximum
137
