Product description
12
3 Product description
The device consists of a transmitter and a sensor.
The device is available as a compact version:
The transmitter and sensor form a mechanical unit.
3.1 Product design
3.1.1 Device version with PROFINET communication protocol
4
3
2
1
 1 Important components of a measuring device
1 Sensor
2 Transmitter housing
3 Main electronics module
4 Transmitter housing cover
5 Transmitter housing cover (version for optional local display)
6 Local display (optional)
7 Main electronics module (with bracket for optional local display)
Proline Promass A 100 PROFINET
5
6
7
