6�8�- Measurement Convention - Circutor CVM-C11 Instruction Manual

Configuration values
Press key
6�8�- MEASUREMENT CONVENTION
You can select the measurement convention of the device from this screen.
Press key
The key
To validate the data, press
Configuration values
Press key
62
Table 28:Configuration values: Number of quadrants�
Possible values
to access the next programming step.
for 3 seconds to edit the value. The
jumps between the possible options.
for 3 seconds and the
Table 29:Configuration values: Measurement convention�
Possible values
to access the next programming step.
Number of quadrants
2, Consumption
4, Consumption and Generation
icon appears at the top of the screen.
icon will disappear from the display.
Measurement convention
Cir Circutor measurement convention.
IEC IEC 61557-12 measurement convention.
IEEE IEEE 1459 measurement convention.
