CVM-C11
7.- CONFIGURATION OF ETHERNET COMMUNICATIONS
Note: Ethernet communications are available on model CVM-C11-ITF-IN-ETH-ICT2.
To enter the configuration menu you must press the
keys for 3 seconds.
To exit the configuration menu, press the
key for 3 seconds.
If a reset is performed before validation or no key is pressed for 30 seconds, the configuration made
is not stored in memory.
Note: In the annex
you can view the configuration tree.
"ANNEX B.- ETHERNET CONFIGURATION MENUS"
7�1�- PROTOCOL
On this screen the Ethernet communications protocol is selected.
Press key
for 3 seconds to edit the value. The
icon appears at the top of the screen.
The key
jumps between the possible options.
To validate the data, press
for 3 seconds and the
icon will disappear from the display.
Configuration values
Table 71:Configuration values: Protocol�
Protocolo
TCP, Modbus TCP
Possible values
bAC, BACnet
Press key
to access the next programming step.
94
Instruction Manual
