6�15�- Backlight, Turning On The Backlit Display - Circutor CVM-C11 Instruction Manual

Configuration values
Press key
This programming step is repeated for each one of the 19 screens of the device.
6�15�- BACKLIGHT, TURNING ON THE BACKLIT DISPLAY
The time that the Backlight will stay lit (in seconds) is programmed on this screen after the last
keystroke on the device.
Press key
To enter or modify the value, press the
When the desired value is shown on the screen, move onto the next digit by pressing the key
modify the other values.
To validate the data, press
The programmed value will be deleted if the entered value is higher than the maximum programming
value.
Configuration values
Note: The value 00 indicates that the backlight will stay permanently lit.
Press key
68
Table 37:Configuration values: Selecting the screens�
Possible values
to access the next programming step.
for 3 seconds to edit the value. The
for 3 seconds and the
Table 38:Configuration values: Backlight�
Minimum value
Maximum value
to access the next programming step.
Selecting the screens
Yes, to display the screen in the user menu.
No, to stop displaying the screen.
icon appears at the top of the screen.
key repeatedly, increasing the value of the flashing digit.
icon will disappear from the display.
Backlight
0 seconds.
99 seconds.
CVM-C11
to
Instruction Manual
