4�1�1�- THD CALCULATION
The device can calculate the Total Harmonic Distortion (THD) using the fundamental component of the
signal (THD) or the effective component (RMS) (thd).
�������� �������� �������� = � � �
For example, the equations for the calculation of the Total Harmonic Distortion of Voltage are:
�������� �������� �������� = � � �
�������� ℎ �������� = � � �
�������� ℎ �������� = � � �
The calculation method to be used by the device is selected in the configuration menu, see
�
CALCULATION"
4�1�2�- MAXIMUM DEMAND
The maximum demand is the average instantaneous measurement over a specific time interval, usually
15 minutes. There are several ways to calculate this parameter:
Fixed Window (by block)
This is the calculation of maximum demand in a specific interval (normally the integration period =
15 minutes). Once the number is calculated, the value is saved and a new calculation for the next 15
minutes begins. The result would be 4 values per hour.
