DESCRIPTION
Energía inductiva gene-
rada
Energía capacitiva ge-
nerada
Energía aparente gene-
rada
Corriente trifásica
(media)
Corriente de neutro
Potencia aparente L1
Potencia aparente L2
Potencia aparente L3
Potencia aparente
trifásica
Máxima demanda I1
Máxima demanda I2
Máxima demanda I3
Máxima demanda A
Máxima demanda kW
Máxima demanda kVA
Analog Value Object Type
1. Dynamically creatable using BACnet's CreateObject service?
2. Dynamically deleatable using BACnet's DeleteObject service?
3. List of optional properties supported:
4. List of all properties that are writable where not otherwise required by this standard
5. List of propietary properties:
Property Identifier
5. List of object identifiers and their meaning in this device
Object ID
AV1
AV2
AV3
Device Object Type
1. Dynamically creatable using BACnet's CreateObject service?
2. Dynamically deleatable using BACnet's DeleteObject service?
3. List of optional properties supported:
4. List of all properties that are writable where not otherwise required by this standard
Object_Name
Max_Master
Max_Info_Frames
Object_Identifier
5. List of propietary properties:
5. List of any property value range restrictions
Property Identifier
Object_Name
114
Three phase generated
reactive inductive energy
Three phase genera-
ted reactive capacitive
energy
Three phase generated
aparent energy
Three phase average
current
Neutral current
Aparent power L1
Aparent power L2
Aparent power L3
Three phase aparent
power
Maximum demand I1
Maximum demand I2
Maximum demand I3
Maximum demand A
Maximum demand kW
Maximum demand kVA
Property Datatype
Object Name
MAC_Address
BaudRate
Device_ID
Restrictions
< 32 bytes
SYMBOL ID OBJECTS
kvarL•h III (-) AI35
kvarC•h III(-) AI36
kVA•h III (-) AI37
I_AVG AI38
In AI39
kVA AI40
kVA AI41
kVA AI42
kVAIII AI43
Md (A1) AI44
Md(A2) AI45
Md(A3) AI46
A III AI47
kW III AI48
kVA III AI49
No
No
No
No
Description, Protocolo_Conformance_Class
CVM-C11
OBJECT NAME UNITS
IndEnergy_exp kvarL•h
CapEnergy_exp kvarC•h
AppEnergy_exp kVA•h
AvgValCurr3Ph I_AVG
NeutralCurrent
AppPwrPh1
AppPwrPh2
AppPwrPh3
AppPw3Ph
MaxDemand_A1
MaxDemand_A2
MaxDemand_A3
MaxDemand_A
MaxDemand_kW
MaxDemand_ kVA
Meaning
Description
MAC
BAUD RATE
DEVICE ID
Instruction Manual
In
kVA
kVA
kVA
kVA
A
A
A
A
kW
kVA
