6�1�3�- QUADRANTS AND MEASUREMENT CONVENTION
This screen enables configuration of the device's working quadrants and measurement convention.
Hold down key
Hold down key
Use keys
 Quadrants:
2Q, The device operates in 2 quadrants.
4Q, The device operates in all 4 quadrants.
 Measurement convention:
IEC, Measurement convention IEC.
CIRC, Measurement convention Circutor.
IEEE, Measurement convention IEEE.
To validate the option, hold down key
Use key
6�1�4�- INSTALLATION TYPE
This screen enables type of installation to be configured
Hold down key
Use keys
4W-3Ph, Three-phase mains measuring with 4-wire connection.
3W-3Ph, Three-phase mains measuring with 3-wire connection
3W-2Ph, Two-phase mains measuring with 3-wire connection
2W-1Ph, Single-phase mains measuring with 2-wire phase-to-phase connection
2W-1Ph, Single-phase mains measuring with 2-wire phase-to-neutral connection
46
to set the quadrant
to set the measurement convention
and to skip through the different options:
to skip to the next programming point.
to enter programming mode.
and to skip through the different options:
